Let us consider

Statistics:-Mode(Binomial(n, p));
                        floor((1 + n) p)

Up to Wiki, the output is not correct. Simply no words.




with(Statistics):````

X := Statistics:-RandomVariable(Normal(0, 1)):

PDF(sin(X), t)

piecewise(t <= -1, 0, t < 1, 2^(1/2)*exp(-(1/2)*arcsin(t)^2)/(Pi^(1/2)*(-t^2+1)^(1/2)), 1 <= t, 0)

(1)

int(%, t = -1 .. 1)

2*erf((1/4)*Pi*2^(1/2))

(2)

evalf(%)

1.767540069

(3)

``


There were recently submitted a dozen Maple bugs by me and others. Maplesoft have brought no responses. They keep strategic silence. True merit is not afraid of criticism.

Download Bug_in_Statistics_PDF.mw

Let us consider

restart; J := int(cos(a*x)^2/(x^2-1), x = -infinity .. infinity, CPV);
-(1/4)*Pi*sin(2*a)*csgn(I*a)-(1/4)*Pi*sin(2*a)*csgn(I/a)

This result is not true for a=I:

eval(J, a = I);
                               0

In this case the integral under consideration diverges because of

cos(I*x)^2;

                            cosh(x) ^2



Let us consider

maximize(int(exp(-x^4), x = k .. 3*k), location);

Error, (in maximize) invalid input: iscont expects its 1st argument, f, to be of type algebraic, but received x = k .. 3*k
whereas the expected output is

[(2*((1/40)*GAMMA(1/4, (1/80)*ln(3))*5^(1/4)*ln(3)^(3/4)-(1/40)*GAMMA(1/4, (81/80)*ln(3))*5^(1/4)*ln(3)^(3/4)))*5^(3/4)*(1/ln(3))^(3/4), [k = (1/10)*10^(3/4)*ln(3)^(1/4)]]

as Mma 11 produces. The following

RealDomain:-solve(diff(int(exp(-x^4), x = k .. 3*k), k));
  -(1/10)*5^(3/4)*ln(3)^(1/4), (1/10)*5^(3/4)*ln(3)^(1/4)

is not a workaround because of

int(exp(-x^4), x = (1/10)*5^(3/4)*ln(3)^(1/4) .. (3/10)*5^(3/4)*ln(3)^(1/4));
  FAIL



Let us consider

MultiSeries:-series(Psi((2*x+1)/(2*x))-Psi((x+1)/(2*x)), x = 0);

x-(1/2)*x^2+(1/4)*x^4-(1/2)*x^6 +O(x^7)

The above result contradicts

MultiSeries:-limit(diff(Psi((2*x+1)/(2*x))-Psi((x+1)/(2*x)), x), x = 0);
                           undefined
MultiSeries:-limit((Psi((2*x+1)/(2*x))-Psi((x+1)/(2*x)))/x, x = 0, right);
                               1
MultiSeries:-limit((Psi((2*x+1)/(2*x))-Psi((x+1)/(2*x)))/x, x = 0, left);
                           undefined
plot((Psi((2*x+1)/(2*x))-Psi((x+1)/(2*x)))/x, x = -0.1e-1 .. 0.1e-2, discont, y = -5 .. 5);

restart; with(Statistics):
X := RandomVariable(Normal(0, 1)): Y := RandomVariable(Uniform(-2, 2)):
Probability(X*Y < 0);

crashes my comp in approximately 600 s. Mma produces 1/2 on my comp in 0.078125 s.

Let us consider

with(Statistics):
X1 := RandomVariable(Normal(0, 1)):
X2 := RandomVariable(Normal(0, 1)):
X3 := RandomVariable(Uniform(0, 1)):
X4 := RandomVariable(Uniform(0, 1)):
Z := max(X1, X2, X3, X4); CDF(Z, t);

int((1/2)*(_t0*Heaviside(_t0-1)-_t0*Heaviside(_t0)-Heaviside(1-_t0)*Heaviside(-_t0)+Heaviside(-_t0)+Heaviside(1-_t0)-1)*(1+erf((1/2)*_t0*2^(1/2)))*(2^(1/2)*Heaviside(_t0-1)*exp(-(1/2)*_t0^2)*_t0-2^(1/2)*Heaviside(_t0)*exp(-(1/2)*_t0^2)*_t0-2^(1/2)*Heaviside(-_t0)*Heaviside(1-_t0)*exp(-(1/2)*_t0^2)-Pi^(1/2)*undefined*erf((1/2)*_t0*2^(1/2))*Dirac(_t0)-Pi^(1/2)*undefined*erf((1/2)*_t0*2^(1/2))*Dirac(_t0-1)+2^(1/2)*Heaviside(-_t0)*exp(-(1/2)*_t0^2)+2^(1/2)*Heaviside(1-_t0)*exp(-(1/2)*_t0^2)-Pi^(1/2)*undefined*Dirac(_t0)-Pi^(1/2)*undefined*Dirac(_t0-1)+Pi^(1/2)*Heaviside(_t0-1)*erf((1/2)*_t0*2^(1/2))-Pi^(1/2)*Heaviside(_t0)*erf((1/2)*_t0*2^(1/2))-exp(-(1/2)*_t0^2)*2^(1/2)+Pi^(1/2)*Heaviside(_t0-1)-Pi^(1/2)*Heaviside(_t0))/Pi^(1/2), _t0 = -infinity .. t)

whereas Mma 11 produces the correct piecewise expression (see that here screen15.11.16.docx).

Edit. Mma output.

Let us consider

J := int(x^n/sqrt(1+x^n), x = 0 .. 1) assuming n > 0;

2*(2^(1/2)-hypergeom([1/2, 1/n], [(n+1)/n], -1))/(2+n)

limit(J,n=infinity);
FAIL
MultiSeries:-limit(J,n=infinity);
FAIL

Mma 11 finds the limit is zero. Hope one feels the difference.

limit((x^2-1)*sin(1/(x-1)), x = infinity, complex);
infinity-infinity*I
MultiSeries:-limit((x^2-1)*sin(1/(x-1)), x = infinity, complex);
infinity

whereas the same outputs are expected. The help http://www.maplesoft.com/support/help/Maple/view.aspx?path=infinity&term=infinity does not shed light on the problem. Here are few pearls:

  • infinity is used to denote a mathematical infinity, and hence it is usually used as a symbol by itself or as -infinity.
  • The quantities infinity, -infinity, infinity*I, -infinity*I, infinity + y*I, -infinity + y*I, x + infinity*I and x - infinity*I, where x and y are finite, are all considered to be distinct in Maple. However, all 2-component complex numerics in which both components are infinity are considered to be the same (representing the single point at the "north pole" of the Riemann sphere).
  • The type cx_infinity can be used to recognize this "north pole" infinity.

Let us consider

MmaTranslator:-FromMma(" Table[0,{n=10},{m=2}]");

[seq([seq(0,i=1..(m := 2))],j=1..(n := 10))]

The above result is syntactically incorrect in Maple language. The translation should be

Matrix(10,2)
#or
[seq([seq(0,i=1.. 2)],j=1..10)]

up to the Mmma's result

Table[0, {n = 10}, {m = 2}]

{{0, 0}, {0, 0}, {0, 0}, {0, 0}, {0, 0}, {0, 0}, {0, 0}, {0, 0}, {0,0}, {0, 0}}

Another bug is as follows.

MmaTranslator:-FromMma("Sinc[x]");

Sinc(x)

whereas the expected result is piecewise(x=0,1,sin(x)/x) up to http://reference.wolfram.com/language/ref/Sinc.html

In general, the MmaTranslator package is outdated. It often returns working Mma's commands as incorrect (Concrete examples are long and need a context. These may be exposed on demand.). The question arises about the quality of other Maple translations.

The command

plots:-implicitplot(evalc(argument((1+x+I*y)/(1-x-I*y))) <= (1/4)*Pi, x = -5 .. 5, y = -5 .. 5, crossingrefine = 1, gridrefine = 2, rational = true, filled, signchange = true, resolution = 1000);

produces an incorrect result

in view of

evalf(argument((1-4+4*I)/(1+4-4*I)));
                          2.889038378

There is a workaround

plots:-inequal(evalc(argument((1+x+I*y)/(1-x-I*y))) <= (1/4)*Pi, x = -5 .. 5, y = -5 .. 5);



The command

restart; st := time(): FunctionAdvisor(EllipticE); time()-st;

produces the result on my comp in 805.484 s. Too much time.

The command

J := int(sin(x)/(x*(1-2*a*cos(x)+a^2)), x = 0 .. infinity)assuming a::real,a^2 <>0;

outputs

(infinity*I)*signum(a^3*(Sum(a^_k1, _k1 = 0 .. infinity))-a^2*(Sum(a^_k1, _k1 = 0 .. infinity))-a*(Sum(a^(-_k1), _k1 = 0 .. infinity))+a^2+Sum(a^(-_k1), _k1 = 0 .. infinity)+a)

which is wrong in view of

evalf(eval(J, a = 1/2));
                       Float(undefined) I

The correct answer is Pi/(4*a)*(abs((1+a)/(1-a))-1) according to G&R 3.792.6. Numeric calculations confirm it.

Both the commands

maximize(x*sin(t)+y*sin(2*t), t = 0 .. 2*Pi)assuming x>=0,y>=0;
minimize(x*sin(t)+y*sin(2*t), t = 0 .. 2*Pi)assuming x>=0,y>=0;

output 0. Simply no words.

The following three commands

plots:-implicitplot(3*cos(x) = tan(y)^3, x = -Pi .. Pi, y = -(1/2)*Pi-1 .. (1/2)*Pi+1, thickness = 3, crossingrefine = 1, rational = true, signchange = true, resolution = 1000, gridrefine = 2);
plots:-implicitplot(3*cos(x) = tan(y)^3, x = -Pi .. Pi, y = -(1/2)*Pi-1 .. (1/2)*Pi+1, thickness = 3, crossingrefine = 1, rational = true, signchange = false, resolution = 1000, gridrefine = 2);
plots:-implicitplot(3*cos(x) = tan(y)^3, x = -Pi .. Pi, y = -(1/2)*Pi-1 .. (1/2)*Pi+1, thickness = 3, crossingrefine = 1, rational = true, resolution = 1000, gridrefine = 2);

produce the same incorrect plot

It is clear the sraight lines given by y=Pi/2 and y=-Pi/2 are superfluous. It should be noticed that the Mmma's ContourPlot command without any options produces a correct plot.
