Question: How to compare two signal to get instant to command a thyristor

Question:How to compare two signal to get instant to command a thyristor

Alger 524 MapleSim
March 29 2012
0

Hi all,

I want to compare two signals where intersections between the two signals represent the instant of command (like boolean pulse) of a thyristor. The two signals are volatges and command of thyristor is boolean. A conversion of voltage to boolean signal should also done, I think ?

Thanks in advance

See image below.
