delvin

20 Reputation

3 Badges

0 years, 204 days

MaplePrimes Activity


These are replies submitted by delvin

@tomleslie



  Thank you for taking time out of your busy day.
   Sincerely,

   delvin

@rcorless

   The equation is correct, but I didn't pay attention, I wrote some in my own language,sorry.

@Rouben Rostamian

   Sorry, I was not paying attention.

      Thanks ocean.

@tomleslie

 Ok, I want to check the different solutions of the equation.



  Thanks a million, You made my day.



@tomleslie

   Thank osean very much for your time.

 "Because the answers are not what I want , The answers obtained are obvious."

m4.mw

@Joe Riel

This is the code I wrote, but it didn't get a good answer

restart

with(student)

U := a[0]+sum(-a[i]*tanh(xi[n])^i, i = 1 .. 1)+sum(-b[i]*tanh(xi[n])^(-i), i = 1 .. 1)

a[0]-a[1]*tanh(xi[n])-b[1]/tanh(xi[n])

(1)

u(xi[n+1]) := a[0]-a[1]*(tanh(xi[n])+tanh(d))/(1+tanh(xi[n])*tanh(d))-b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])+tanh(d))

a[0]-a[1]*(tanh(xi[n])+tanh(d))/(1+tanh(xi[n])*tanh(d))-b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])+tanh(d))

(2)

u(xi[n-1]) := a[0]-a[1]*(tanh(xi[n])-tanh(d))/(1+tanh(xi[n])*tanh(d))-b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])-tanh(d))

a[0]-a[1]*(tanh(xi[n])-tanh(d))/(1+tanh(xi[n])*tanh(d))-b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])-tanh(d))

(3)

eq := c*(diff(U, xi))-(U^2+U*beta+alpha)*(u(xi[n+1])-u(xi[n-1]))

-((a[0]-a[1]*tanh(xi[n])-b[1]/tanh(xi[n]))^2+(a[0]-a[1]*tanh(xi[n])-b[1]/tanh(xi[n]))*beta+alpha)*(-a[1]*(tanh(xi[n])+tanh(d))/(1+tanh(xi[n])*tanh(d))-b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])+tanh(d))+a[1]*(tanh(xi[n])-tanh(d))/(1+tanh(xi[n])*tanh(d))+b[1]*(1+tanh(xi[n])*tanh(d))/(tanh(xi[n])-tanh(d)))

(4)

U := a[0]-a[1]*tanh(xi[n])-b[1]/tanh(xi[n])

a[0]-a[1]*tanh(xi[n])-b[1]/tanh(xi[n])

(5)

simplify(eq); fin1 := simplify(numer(%))

-2*(tanh(xi[n])^4*a[1]^2-a[1]*(beta+2*a[0])*tanh(xi[n])^3+(beta*a[0]+a[0]^2+2*a[1]*b[1]+alpha)*tanh(xi[n])^2-b[1]*(beta+2*a[0])*tanh(xi[n])+b[1]^2)*tanh(d)*((b[1]*tanh(d)^2-a[1])*tanh(xi[n])^2+2*tanh(xi[n])*tanh(d)*b[1]+tanh(d)^2*a[1]+b[1])

(6)

subs(tanh(xi[n]) = Psi, fin1); fin := simplify(%)

2*(Psi^4*a[1]^2-a[1]*(beta+2*a[0])*Psi^3+(beta*a[0]+a[0]^2+2*a[1]*b[1]+alpha)*Psi^2-b[1]*(beta+2*a[0])*Psi+b[1]^2)*((-Psi^2*b[1]-a[1])*tanh(d)^2-2*Psi*tanh(d)*b[1]+Psi^2*a[1]-b[1])*tanh(d)

(7)

for i from 0 to degree(fin, Psi) do EQ[i] := simplify(coeff(fin, Psi, i)) end do

2*a[1]^2*(-b[1]*tanh(d)^2+a[1])*tanh(d)

(8)

Eqs := {seq(EQ[i], i = 0 .. 6)}

Sol := solve(Eqs, {c, a[1], b[1]})

{c = c, a[1] = 0, b[1] = 0}

(9)



Download m3.mw

@acer

okey

@dharr thanks an ocean

@dharr Thanks

NULL

restart;
with(PDEtools):


pde2:=-lambda*diff(y(xi),xi)+y(xi)*diff(y(xi),xi)+diff(y(xi),xi$2)=0;

-lambda*(diff(y(xi), xi))+y(xi)*(diff(y(xi), xi))+diff(diff(y(xi), xi), xi) = 0

(1)



NULL

phi(xi):=(p[1]*exp(q[1]*xi)+p[2]*exp(q[2]*xi))/(p[3]*exp(q[3]*xi)+p[4]*exp(q[4]*xi));
eval(phi(xi),[p[1]=I,p[2]=-I,p[3]=1,p[4]=1,q[1]=I,q[2]=-I,q[3]=I,q[4]=-I]);
simplify(%);
phi(xi):=%;
U(xi):=A[0]+sum(A[d]*phi(xi)^d,d=1)+sum(B[d]*phi(xi)^(-d),d=1);

(p[1]*exp(q[1]*xi)+p[2]*exp(q[2]*xi))/(p[3]*exp(q[3]*xi)+p[4]*exp(q[4]*xi))



(I*exp(I*xi)-I*exp(-I*xi))/(exp(I*xi)+exp(-I*xi))



-sin(xi)/cos(xi)



-sin(xi)/cos(xi)



A[0]-A[1]*sin(xi)/cos(xi)-B[1]*cos(xi)/sin(xi)

(2)

subs(y(xi)=U(xi),pde2);

-lambda*(diff(A[0]-A[1]*sin(xi)/cos(xi)-B[1]*cos(xi)/sin(xi), xi))+(A[0]-A[1]*sin(xi)/cos(xi)-B[1]*cos(xi)/sin(xi))*(diff(A[0]-A[1]*sin(xi)/cos(xi)-B[1]*cos(xi)/sin(xi), xi))+diff(diff(A[0]-A[1]*sin(xi)/cos(xi)-B[1]*cos(xi)/sin(xi), xi), xi) = 0

(3)




Download test1.mw

@Rouben Rostamian

Thanks an ocean

@Rouben Rostamian



Dear Rouben Rostamian,

thank you for your explanation. You can see where this last part of the code is wrong. It is for balancing and obtaining the balance number.

@Rouben Rostamian

hi,thank you



Thank you very much for your help
Where is this code wrong?


>
Error, `>` unexpected
restart;
with(PDEtools):
#local gamma:
get_order:=proc(expr,fun,var)
  local the_list,i;
  the_list := convert( indets(expr, function),list);
  PDETools:-difforder(select( i-> has(i, diff(fun,var)),the_list))
end proc:
DGP:=proc(ff,var) local ee;
  ee:=combine(frontend(expand,[ff]),':-power');
  max(map(proc(u,v)
      if u::`*` then
        op(2,combine(select(type,u,
                            identical(v)^anything),
                     ':-power'));
      else
        if type(u,identical(v)^anything) then
          op(2,u);
        else return FAIL end if;
      end if;
    end proc,
    [`if`(ee::`+`,op(ee),ee)],var));
end proc:


fracdiff(u(x,t), x, alpha) assuming alpha > 0, alpha < 1:
FPDE := % + u(x,t)*diff(u(x,t),x) + diff(u(x,t),x,x) = 0;

    /   /         (-alpha) /  d            \              \\
    |   |(x - tau)         |----- u(tau, t)|              ||
    |   |                  \ dtau          /              ||
    |int|-----------------------------------, tau = 0 .. x||
    \   \         GAMMA(1 - alpha)                        //

                 / d         \   / d  / d         \\
       + u(x, t) |--- u(x, t)| + |--- |--- u(x, t)|| = 0
                 \ dx        /   \ dx \ dx        //
pde1 := D^alpha*u(x,y,t)+u(x,y,t)*diff(u(x,y,t),x)+diff(u(x,y,t),x$2)=0;

tr1 := {u(x,t) = y(xi),  xi = x - v*t^alpha,  v = lambda*t^alpha / GAMMA(alpha+1)};

         alpha                         / d            \
        D      u(x, y, t) + u(x, y, t) |--- u(x, y, t)|
                                       \ dx           /

             / d  / d            \\
           + |--- |--- u(x, y, t)|| = 0
             \ dx \ dx           //
   /             alpha                                      \
   |     lambda t                     alpha                 |
  < v = ----------------, xi = x - v t     , u(x, t) = y(xi) >
   |    GAMMA(alpha + 1)                                    |
   \                                                        /


pde2:=diff(y(xi), xi, xi) + y(xi)*diff(y(xi),xi) - lambda*diff(y(xi),xi) = 0;

/ d   / d        \\         / d        \          / d        \
|---- |---- y(xi)|| + y(xi) |---- y(xi)| - lambda |---- y(xi)| = 0
\ dxi \ dxi      //         \ dxi      /          \ dxi      /
n[1]:=get_order(pde2, U(xi),xi);
el1:=select(has, expand(lhs(pde2)), diff(U(xi), xi$n[1]));
n[2]:=degree(expand(eval(lhs(pde2),diff=0)),U(xi));
el2:=select(has, expand(lhs(pde2)), U(xi)^(n[2]));
eq3:=expand(eval(el1,[U(xi)=a[h]*xi^(-h)]));
eq4:=expand(eval(el2,[U(xi)=a[h]*xi^h]));
d1:=DGP(eq3, xi) assuming h>0;
d2:=DGP(eq4, xi) assuming h>0;
assign(solve(-d1=d2,{h}));
print("N"=h);
                               0
Error, invalid input: diff expects 2 or more arguments, but received 1
                           -infinity
                               0
                              el1
                               0
                              FAIL
                              FAIL
                            "N" = h
