Maple 2022 Questions and Posts

These are Posts and Questions associated with the product, Maple 2022

I  generated some graphs via maple and would like to put them in my paper. So I am going to convert the following worksheet to pdf.

with(GraphTheory):
Graphs:=[NonIsomorphicGraphs(6,8,output=graphs,outputform = graph)]:
num_g:=nops(Graphs):
num:=ceil((num_g)/5.):
M1:=Matrix (num,5,(i,j)->`if`((i-1)*5+j<=num_g, DrawGraph(Graphs[(i-1)*5+j],size=[250,250] ,overrideoptions ,showlabels=false,style=planar, stylesheet =  [
 vertexcolor     = orange
,vertexfontcolor = black
,vertexborder    = false
,edgethickness   = 0.6
,edgecolor       = MidnightBlue
,vertexshape     =  "circle"
,vertexfont      = [Arial, 4],
vertexthickness=5], caption = cat(H__,5*(i-1)+j),captionfont=["ROMAN",7]),plot(x = 0 .. 1, axes = none))):
DocumentTools:-Tabulate (M1[1..5,.. ],widthmode=percentage ,width=80 , exterior =all) :





But there was a problem with the exported pdf. There was some mosaic stuff at the vertices of all those graphs. It was strange. (I want to reduce the size of vertices of the graphs in order not to look crowded.)



Only when I insert the option vertexpadding and set a large enough size  of vertex (for this example, we set vertexpadding=7),  it won't go wrong. However, in fact, we often need make vertice‘s size smaller , especially when there are more vertices.

I need to make my base class local variable static, so that when extending the class, the subclass will share these variable and use their current values as set by the base class. If I do not make them static, then the base class when extended, will get fresh instance of these variable, losing their original values, which is not what I want.

To do this, one must make the base class variables static

This works, but now I do not know the syntax where to put the type on the variable.

I can't write   local m::integer::static; nor local m::static::integer;

I could only write local m::static; but this means I lost the ability to have a type on the variable and lost some of the type checking which is nice to have in Maple. From Maple help:



Here is example

restart;

base_class:=module()
  option object;
  local n::static;  #I want this type to ::integer also. But do not know how

  export set_n::static:=proc(_self,n::integer,$)
     _self:-n := n;
  end proc;

  export process::static:=proc(_self,$)
    local o;
    o:=Object(sub_class);
    o:-process();
  end proc;
end module;

sub_class:=module()
   option object(base_class);
   process:=proc(_self,$)
      print("in sub class. _self:-n = ",_self:-n);
   end proc;
end module;

o:=Object(base_class);
o:-set_n(10);
o:-process()


            "in sub class. _self:-n = ", 10

The above is all working OK. I just would like to make n in the base class of type ::integer as well as ::static

Is there a syntax for doing this?



I have a set of formulas I saved in a matrix and the exported the matrix to Excel. However when I open the file in Excel the equations are in prefix notation (I think).  That's not exactly human readable friendly.  If I copy and paste straight into excel they are readable.

It there a way to make the Maple export similar?

EDIT:-  I exported as a.csv file because if export as .xlsx    all the equation change into "#NUM!" in the spreadsheed.

restart

NULL

Digits := 5

5

(1)

interface(displayprecision = 5); interface(rtablesize = 30)

5

(2)

cosrule := proc (a, b, c, A) options operator, arrow; a^2 = b^2+c^2-2*b*c*cos(A) end proc

proc (a, b, c, A) options operator, arrow; a^2 = b^2+c^2-2*b*c*cos(A) end proc

(3)

Ang := solve(cosrule(a, b, c, A), A)

Pi-arccos((1/2)*(a^2-b^2-c^2)/(b*c))

(4)

Formulas := Matrix(20, 4)









data := [L[1] = 619.35, L[2] = 891.12, pos = 180, tos = 90, x1 = 600, y1 = -800, z1 = 500, x2 = 900, y2 = -200, z2 = 850, `&Theta;t` = 29.34*Pi*(1/180), `&Theta;p` = 53.98*Pi*(1/180)]








i := 3

res0 := `&Delta;Z` = z2-z1; Formulas[i, 1] := lhs(res0); Formulas[i, 2] := rhs(res0)

`&Delta;Z` = z2-z1

(5)

res0 := eval(res0, data); Formulas[i, 3] := rhs(res0); Formulas; i := i+1

`&Delta;Z` = 350

(6)

res1 := dt[1] = sqrt(tos^2+L[1]^2); Formulas[i, 1] := lhs(res1); Formulas[i, 2] := rhs(res1); res1 := eval(res1, data); Formulas[i, 3] := rhs(res1); Formulas; i := i+1

dt[1] = 625.85

(7)

NULL

res2 := d[1] = sqrt(pos^2+tos^2+L[1]^2); Formulas[i, 1] := lhs(res2); Formulas[i, 2] := rhs(res2); res2 := eval(res2, data); Formulas[i, 3] := rhs(res2); Formulas; i := i+1

d[1] = 651.22

(8)

res3 := dt[2] = sqrt(tos^2+L[2]^2); Formulas[i, 1] := lhs(res3); Formulas[i, 2] := rhs(res3); res3 := eval(res3, data); Formulas[i, 3] := rhs(res3); Formulas; i := i+1

dt[2] = 895.65

(9)

NULL

res4 := d[2] = sqrt(pos^2+tos^2+L[2]^2); Formulas[i, 1] := lhs(res4); Formulas[i, 2] := rhs(res4); res4 := eval(res4, data); Formulas[i, 3] := rhs(res4); Formulas; i := i+1

d[2] = 913.56

(10)

NULL

res7 := tau = arctan(tos/L[1]); Formulas[i, 1] := lhs(res7); Formulas[i, 2] := rhs(res7); res7 := eval(res7, data); Formulas[i, 3] := rhs(res7); 180*(eval(rhs(`%%`), data))/Pi; Formulas[i, 4] := %; Formulas; i := i+1

8.2678

(11)

NULL

res8 := rho = arctan(tos/L[2]); Formulas[i, 1] := lhs(res8); Formulas[i, 2] := rhs(res8); res8 := eval(res8, data); Formulas[i, 3] := rhs(res8); 180*(eval(rhs(`%%`), data))/Pi; Formulas[i, 4] := %; Formulas; i := i+1; data := [op(data), res0, res1, res2, res3, res4, res7, res8]

5.7674

(12)

NULL

res9 := alpha = `&Theta;t`+tau-rho; Formulas[i, 1] := lhs(res9); Formulas[i, 2] := rhs(res9); res9 := eval(res9, data); Formulas[i, 3] := rhs(res9); 180*(eval(rhs(`%%`), data))/Pi; Formulas[i, 4] := %; Formulas; i := i+1; data := [op(data), res9]

31.840

(13)

NULL

NULL

NULL

res10 := dt[3] = solve(cosrule(dt[3], dt[2], dt[1], alpha), dt[3])[1]; Formulas[i, 1] := lhs(res10); Formulas[i, 2] := rhs(res10); res10 := eval(res10, data); Formulas[i, 3] := rhs(res10); Formulas; i := i+1; data := [op(data), res10]

dt[3] = 491.45

(14)

NULL

NULL

res11 := beta = solve(cosrule(dt[1], dt[2], dt[3], beta), beta); Formulas[i, 1] := lhs(res11); Formulas[i, 2] := rhs(res11); res11 := eval(res11, data); Formulas[i, 3] := rhs(res11); 180*(eval(rhs(`%%`), data))/Pi; Formulas[i, 4] := %; Formulas; i := i+1; data := [op(data), res11]

42.215

(15)

NULL

NULL

NULL

NULL

res12 := Zeta = arccos(`&Delta;Z`/dt[3]); Formulas[i, 1] := lhs(res12); Formulas[i, 2] := rhs(res12); res12 := eval(res12, data); Formulas[i, 3] := rhs(res12); 180*(eval(rhs(`%%`), data))/Pi; Formulas[i, 4] := %; Formulas; i := i+1; data := [op(data), res12]

44.588

(16)

NULL

NULL

res13 := dt[4] = dt[3]*sin(Zeta); Formulas[i, 1] := lhs(res13); Formulas[i, 2] := rhs(res13); res13 := eval(res13, data); Formulas[i, 3] := rhs(res13); Formulas; i := i+1; data := [op(data), res13]

Matrix(%id = 36893490716944981036)

(17)



``

NULL

``

NULL

currentdir()

"C:\Users\Ronan\Documents\MAPLE\A & Q Maple primes"

(18)

NULL

with(ExcelTools)

[Export, Import, WorkbookData]

(19)

NULLExport(Formulas, "Frmls.csv")NULL

Download test_eqn_export.mw

Hi.

What wrong could be there with the color line?

restart:

with(plots):

equ1 := BesselJ(sqrt(17)/2, 10*sqrt(t)*sqrt(2))/t^(1/4) + BesselY(sqrt(17)/2, 10*sqrt(t)*sqrt(2))/t^(1/4):

equ2 := BesselJ(sqrt(17)/2, 10*sqrt(t)*sqrt(2))/t^(1/4) + 5*BesselY(sqrt(17)/2, 10*sqrt(t)*sqrt(2))/t^(1/4):

equ3 := BesselJ(sqrt(17)/2, 10*sqrt(t))/t^(1/4) + 5*BesselY(sqrt(17)/2, 10*sqrt(t))/t^(1/4):

tmax   := 30:
colors := ["Red", "Violet", "Blue"]:

p1 := plot([equ1, equ2, equ3], t = 0 .. tmax, labels = [t, T[2](t)], tickmarks = [0, 0], labelfont = [TIMES, ITALIC, 12], axes = boxed, color = colors):

ymin := min(op~(1, op~(2, op~(2, [plottools:-getdata(p1)])))):
ymax := max(op~(2, op~(2, op~(2, [plottools:-getdata(p1)])))):
dy   := 2*ymax:

legend1 := typeset(C[3] = 1, ` , `, C[4] = 1, ` , `, Omega^2 = 50):
legend2 := typeset(C[3] = 1, ` , `, C[4] = 5, ` , `, Omega^2 = 50):
legend3 := typeset(C[3] = 1, ` , `, C[4] = 5, ` , `, Omega^2 = 25):

p2 := seq(textplot([tmax-2, ymax-k*dy/20, legend||k], align=left), k=1..3):

p3 := seq(plot([[tmax-2, ymax-k*dy/20], [tmax-1, ymax-k*dy/20]], color=colors[k]), k=1..3):
display(p1, p2, p3, view=[default, -ymax..ymax], size=[800, 500])

Error, (in plot) invalid color specification: colors[1]



display(p1, p2, p3, view = [default, -ymax .. ymax], size = [800, 500])

(1)



Download Legend_Inside.mw

  1. I use both Maple and Matlab
  2. I also install (a stripped down version of) Maple as the "symbolic toolbox" for Matlab using the executable MapleToolbox2022.0WindowsX64Installer.exe, which lives in C:\Program Files\Maple 2022. This gives me acces to (some) symbolic computation capability from within Matlab.
  3. This installation process has been working for as long as I remember, certainly more than 10 years
  4. With Maple 2022 and Matlab R2022a, this installation process ran with no problems and I can perform symbolic computation within Matlab
  5. However, although the Matlab help lists the Maple toolbox as supplemental software (as in all previous releases), I can no longer acces help for Maple from within Matlab - I just get a "Page not found" message
  6. The relevant Maple "help" is at the same place within the Matlab folder structure which is C:\Program Files\MATLAB\R2022a\toolbox\maple\html
  7. I have just spoken to support at Matlab and they claim tha this must be a Maple (or Maple toolbox installer issue) - so nothing to do with them!
  8. Has anyone else had a similar problem andd found a workaround?

When using the built-in fsolve function to find the roots of a polynomial, how does exponentiation occur? For example, x3 is found​​​​​​first, and then to find x4, will he start again from the beginning, that is, x*x*x*x, or will he take the value of x3​​​​​​ and multiply by x? The teacher is interested in finding out this, but I don't know how to find out myself.

To Maple support:

I was investigating this pde from a different forum.

I noticed that when using an expanded version of the pde, Maple hangs. Without expanding the PDE, Maple gives an answer in 2 seconds.

Why does expanding the PDE makes a difference? I do not have an earlier version of Maple on my new PC to check if this is a new issue or not.


interface(version);

`Standard Worksheet Interface, Maple 2022.0, Windows 10, March 8 2022 Build ID 1599809`

Physics:-Version()

`The "Physics Updates" version in the MapleCloud is 1230 and is the same as the version installed in this computer, created 2022, April 21, 9:8 hours Pacific Time.`

restart;
pde1:=VectorCalculus:-Laplacian(u(r,theta),'polar'[r,theta]);
pde1_expanded:=expand(pde1);
bc  := u(1,theta)=sin(theta)^4,u(3,theta)=1;
pdsolve([pde1=0,bc],u(r,theta))


(diff(u(r, theta), r)+r*(diff(diff(u(r, theta), r), r))+(diff(diff(u(r, theta), theta), theta))/r)/r

(diff(u(r, theta), r))/r+diff(diff(u(r, theta), r), r)+(diff(diff(u(r, theta), theta), theta))/r^2

u(1, theta) = sin(theta)^4, u(3, theta) = 1

u(r, theta) = (1/52480)*((328*r^6-26568*r^2)*ln(3)*cos(2*theta)+(-r^8+6561)*ln(3)*cos(4*theta)+19680*(ln(3)+(5/3)*ln(r))*r^4)/(ln(3)*r^4)

pdsolve([pde1_expanded=0,bc],u(r,theta)); #HANGS, Waited more than 40 minutes.






Download hangs_pde.mw

Hi everyone! I'd really appreciate if I could get pointed in the right direction as I am a brand new maple user.

So im trying to solve this constrainted optimization problem (See picture) using Maple symbollically. I believe I should have a closed form solution given I can substitute the one constraint into the objective function. Specifically closed form solutions for the three phi variables.

Can someone point me in the right direction as to how I should go about this? I've already taken first order conditions and tried to using the solve() function to no avail, realizing my sytem of equations weren't linear );.

Hi there.

There is some floating bug in Thread-Seq.

Maple is crashing sometimes (not always, 50/50) after running the script below:

thread-seq_error.mw

What's going on?

Hi,all

I am new in Maple,when I execute the "InversePlot" command ,all functions were correct except for exp(x), error occurs as follows, can anyone tell me what mistake I took?

Tks in advance!

restart;
with(Student[Calculus1]);

InversePlot(exp(x), -1 .. 1);
Error, (in Student:-Calculus1:-InversePlot) module does not export `IsTrigProc`



Tks for all you guys.

I have uninstall Maple and deleted the installed directory ,clear the register,reinstall Maple 2022, now all works well.

I think the problem is I installed Maple 2022 in the old directory of 2021for keeping my configuration,this caused much unexpected problem

> with(LinearAlgebra) :
> a:=<<.1,.2>|<.3,.4>>:
> ScalarMultiply(a,.1);

INTEL MKL ERROR: /home/jet08013/maple2022/bin.X86_64_LINUX/libmkl_gf_lp64.so: undefined symbol: mkl_blas_cdgmm_batch_strided.
Intel MKL FATAL ERROR: Cannot load libmkl_gf_lp64.so.
maple: fatal error, lost connection to kernel

This is EXTREMELY inconvenient.

Maple 2022:

It appears that one can use push_back() with an empty DEQueue(), but not push_front().

Since the queue is double-ended and empty, this doesn't make much sense to me. So should this be considered a "bug"?

See the attached

  restart:

#
# This works
#
  A:=DEQueue();
  empty(A);
  push_back(A,2);


module DEQueue () local num, head, tail, storage, dsp; option object; end module



true



module DEQueue () local num, head, tail, storage, dsp; option object; end module

(1)

#
# But this results in an error!
#
  B:=DEQueue();
  empty(B);
  push_front(B,2);

module DEQueue () local num, head, tail, storage, dsp; option object; end module



true



Error, invalid return value from method moduledefinition: 'NULL'





Download DEQueue_Prob.mw

I knew it can't be true that timelimit in Maple 2022 no longer hangs and it is only a matter of time before I find a case where it still hangs.

Here are examples. timelimit hangs. No error or anything, it just hangs. timelimit is just ignored. set the limit to 60 seconds  (CPU time), and waited for 20 minutes (real time) and nothing happend.

I hope in Maple 2023 this will be fixed. Could others confirm this? it only hangs when adding the method=_RETURNVERBOSE otherwise it does not hang.

interface(version);

`Standard Worksheet Interface, Maple 2022.0, Windows 10, March 8 2022 Build ID 1599809`

Examples of timelimit hangs in Maple 2022



Example 1

restart;

integrand:=(B*x+A)/(c*x^2+b*x+a)^2/(f*x^2+e*x+d)

try
  timelimit(60,int(integrand,x,method=_RETURNVERBOSE));
catch:
  print("Timed out");
end try;



Example 2

restart

integrand:=(5*x^4-x^3+3*x^2+x+2)*(2*x^2-x+3)^(1/2)/(5+2*x)^3

try
    timelimit(60,int(integrand,x,method = _RETURNVERBOSE));
catch:
  print("Timed out");
end try;





Download int_hangs.mw

This is a serious problem.

I change "how should maple handle the creation of new math engine?" to "Create new engine for each document". Then click on "Apply globally".  This is under Tools->Options->General

After I close Maple and start it again, I found it back to "Share one engine among all documents" ??

Why is that and how to make this permanent?

Btw, the start Maple 2022 icon still says "Maple 2022 shared server". THis is in the start program menu. I complained about this in Maple 2021 but it is still not fixed.  https://www.mapleprimes.com/questions/231901-Why-Maple-2021-Only-Shows-shared-Server

I do not think this has anything to do with it. But who knows.

I noticed this when I started new worksheet and could not do anything in it because another worksheet was running something even though I made sure I had set the engine to start new one for each worksheet (this is the very first thing I do after I install Maple each time).

Any workaround to make the setting for the engine not change after closing Maple?

Windows 10. Maple 2022.
