@eslamelidy If you use a variable b[2], then this is part of a table called b, so you cannot then use b as a variable name. I fixed this and showed how to get the table outputs you want. I'm assuming you want all these quantities at z=500.

However, you have not properly converted the integrals. The integrand of M__2 had only the integration variable t (and not z) so I used eval to substitute t for z to make the differential equation (this was just to avoid making editing errors and save me time, you could just enter the z's by hand). I then had a differential equation for M__2. But then this gets multiplied by z in creating M, which is a combination of M__2 etc. But there should be no differential equation for M. You have somehow combined into a single differential equation for M, but this has z and t together, and when you substitute t for z you just get zero, which you can see in the output of dsol3: M(z) and Mc(z) are always zero.

So you only convert M__2 etc that were integrals to differential equations, not M or Mc or N or Nc.

 final3.mw

@eslamelidy Yes, in my method the integrals (M[1] etc) are calculated at the same time as the (other) differential equations, which makes it efficient. (You can compare these with the integrals you had after if you like.)

@eslamelidy I've started to change the worksheet, and think that if you do the rest it should work, Just to repeat, you don't need the integrals if you have the corresponding ODEs, for example f(z) = Int(sin(t),t=0..z) is the solution to diff(f(z),z)=sin(z) with initial condition f(0)=0.

final2.mw



@eslamelidy You have done a lot of cutting and pasting to get the "known" functions H(z) etc, which presumably are related simply to M[1] etc, but this is not clear in the worksheet you have given, so it is not obvious to me how to implement the details of the idea I am suggesting. You need to clearly specify how H(z) etc were constructed from the simpler functions.

I don't understand your remark.

@Carl Love I'm not seeing that in 2017.3. Executing the first time doesn't give any indication, but the second time I select and "!" (or ctrl-E) the highlighted line moves to the line with the error but no underline appears. Perhaps I'm missing a reqruired setting. I can live with the highlighted line.

CodeEdit.mw

@Carl Love Thanks - I missed the tooltip, but as you say, syntax errors aren't too hard to find. Not sure why the same mechanism wouldn't work in a regular code edit region.

@ebrahimina LinearSolve will be faster and more accurate than finding the inverse then multiplying. Since you have a generalized eigenvalue problem, you could just use the Eigenvectors command directly Eigenvectors(FF1,FF2). (But for non-square matrices not sure what inverse you want,...)

Finding the inverse could be part of the problem if it is ill-conditioned. So if you can use Eigenvectors, you may not need Digits=30. You really, really need to decide what part of your calculation is requiring this accuracy and improve/avoid it.



@awass I agree it is a bug.

I take @tomleslie's point that floating point arithmetic may make things that are linearly dependent seem linearly independent and too many vectors are returned, and his and @vv's solutions to get rid of extra one(s) are certainly useful for the case where n-component vectors give <=n solutions.

But for 3-component vectors, the routine should never attempt to give more than 3 vectors, so I consider that a bug, and not just possibly a bug.

@Mac Dude I suppose if I were looking for density of various substances, I'd look in a table listing properties of various substances, not just elements. Maple has the ThermophysicalData package, which seems more appropriate (and does have densities), but the database only has fluids. Perhaps there are plans for expansion of that for other materials....

This gives -1 in Maple 2015 but doesn't work in 2017. Don't have 2018...

@Bland3

shape=hermitian can be used if the matrices are going to be complex. This forces real eigenvalues for a floating point calculation.

You are worried that two zero eigenvalues not being exactly the same, and suggest that the one that is not exactly zero has the wrong symmetry for its eigenvector. But from a numerical point of view at Digits=15, these are both zero. I think the eigenvector algorithm is robust, and the symmetry issue is not related to the numerical roundoff in the eigenvalue, if that is what you are suggesting. You can take the Matrix with integer (or exact rational) entries and use NullSpace(M) to see an exact pair of eigenvectors for the zero eigenvalues. Your <0,-1,0,-1> and <1,0,-1,0> are an exact pair.

Probably you know this already, but the non-degenerate eigenvalues have unique eigenvectors up to a scalar multiplication, so the eigenvectors for E and -E will automatically have the required symmetry if E and -E are non-degenerate. Then you can just sort the eigenvectors to have them next to each other (and scale them) if that is what you want.

Once you have degeneracy, then mathematically there is no preferred form for the eigenvectors. So what you want to do is find a linear combination of the ones you get in some prescribed form. I don't see a simple way to do this. On the other hand, degeneracy usually arises from some sort of symmetry, so knowing more about the matrix structure might help you, e.g., if you can partition them into related blocks.

I'm still confused over whether you think the zero eigenvectors can alsways have the <u,v> <v,u> symmetry as I think you originally proposed, or now you think <u,u>, <v,v>?

@dharr - oops, I was careless here. The eigenvectors for zero don't have the [x,-x] symmetry here, entries 1,2,4 are negative of 5,6,8 but entry 3 is not negative of entry 7.

Leaving the entries as integers, so there are no numerical issues, NullSpace(M) gives

[0,0,1,0,0,0,1,0] and [49/5, -56/5, 21/5, -1, -49/5, 56/5, 0,1]

@Bland3 for the plot issue, you can use: seq(plotter[i],i=1..4*L)

To avoid us cutting and pasting, please upload the worksheet using the fat green up-arrow in in the Mapleprimes editor.

@jthress1 From a physical point of view, you have 4 equal eigenvalues and 4 eigenvectors, and for most purposes (say various expansion theorems) you could arbitrarily associate them in 1:1 fashion, and get the same answer. But you almost certainly can't just use one. The eigenvalues also aren't unique, so you could take linear combinations and find another (linearly independent) set of 4.

So I suspect you could take the 6 eigenvectors in a matrix and continue to calculate other quantities, but that depends on the physical context I guess.
