@Carl Love

Either you misinterpreted or either I poorly explained myself, but there is effectively some disagreement.
What I wanted to say writing "NormInv is not so fast" is more precisely : "NormInv doesn't dramatically reduce the time to estimate quantiles for it's barely twice as fast as the latter"

Please, return to my first post and look to the factor 30 between what you said is a "magic" approximation and Quantile.
Of course this speed comes to a price, which is that the approximations are less precise than which you obtain.
So, from the problematic of fast approximations (and the second term is very important which means "we accept to have an error of, let's say, 10-6), the "magic" approximation outperforms NormInv.

You can object that the most important point is accuracy and that NormInv ia about twice faster than Quantile while being more precise, and I agree with that. But if you have, lets say, 106 or more, quantiles to estimate the "magic" method becomes really more interesting than NormInv.

You compute quantiles for probabilities as high as 1-10-20 and, I agree with that too, NormInv is by far better than the "magic" method. But "in practice", that is in usual statistics, you never have to compute such extremely extreme quantiles.
Look, in advanced technology the target reliability of systems is generally between 10-8 and 10-6 , and even: very small failure probabilities are often obtained by using redundancy or connecting such systems in some adhoc way.
What you need is then to estimate probabilities of this magnitude or, reciprocally, to estimate quantiles which (in the normal case) do not exceed +/-6 (which is in fact the idea of this popular, in some circles, "6 sigmas" method).

To set a final point to this debate:

  1. NormInv outperforms Quantile and it could become an improvement of this latter in future Maple's version
  2. Despite it's qualities NormInv doesn't fit the objective of much faster approximations of Quantile in the sense I tried to detial above
  3. It may be a pity that you spent so much time developing, in a direction that was not what I expected, my initial post which the main objective was to put attention on an improvement of the Abramowitz-Stegun's 26.2.23 formula (more generally to point out that this book can contain little errors).
    I should have been clearer... but you quickly steered the debate in a particular direction  saying "I find it hard to believe that any of these "magic coefficients" methods are generally better than this simple Newton's method, which only took 10 minutes to write, can be understood immediately, and works for any setting of Digits or in evalhf mode".
    Looking retrospectively to the whole time spent, it was really much ado about nothing


Thank's for your involvement.

Here is the last test performed.



Time and accuracy test of Newton's method inverse CDF of the Normal distribution

restart:

kernelopts(version);

`Maple 2015.2, APPLE UNIVERSAL OSX, Dec 20 2015, Build ID 1097895`

(1)

#Symbolic steps:
Ncdf:= unapply(int(exp(-x^2/2)/sqrt(2*Pi), x= -infinity..X), X):
Newton:= unapply(simplify(x-(Ncdf(x)-Q)/D(Ncdf)(x)), (x,Q)):

#Purely numeric procedures:
NormInv_inner:= proc(Q, z0, eps)
local z:= z0, z1, e:= infinity, e1;
   do
      z1:= evalf(Newton(z,Q));
      e1:= abs(z1-z);
      if e1 < eps or e1 >= e then return (z+z1)/2 fi;
      e:= e1;
      z:= z1
   od
end proc:

NormInv:= proc(Q::And(numeric, realcons, satisfies(Q-> 0 <= Q and Q <= 1)))
local r;
   if Q > 1/2 then return -thisproc(1-Q) fi;
   if Q = 0 then return -infinity fi;
   r:= evalhf(
      NormInv_inner(
         Q,
         (Q-0.5)*sqrt(2.*Pi),
         max(10.^(1-Digits), evalhf(DBL_EPSILON))
      )
   );
   if Digits <= evalhf(Digits) then r else NormInv_inner(Q, r, 10.^(1-Digits)) fi
end proc
:

Digits:= 20:

randomize(156606905209673);

156606905209673

(2)

S:= Statistics:-Sample(Uniform(0,1), 10^4):

N_Newton:= CodeTools:-Usage(NormInv~(S)):

memory used=0.64GiB, alloc change=364.01MiB, cpu time=6.24s, real time=6.07s, gc time=460.08ms



N_Quantile:= CodeTools:-Usage(Statistics:-Quantile~(Normal(0,1), S)):

memory used=1.41GiB, alloc change=128.00MiB, cpu time=15.00s, real time=14.35s, gc time=1.16s



Statistics commands tend to run faster if you first declare a RandomVariable::

N01:= Statistics:-RandomVariable(Normal(0,1)):

N_rv:= CodeTools:-Usage(Statistics:-Quantile~(N01, S, numeric)):

memory used=1.37GiB, alloc change=0 bytes, cpu time=13.29s, real time=12.51s, gc time=1.21s



Check the accuracy:

LinearAlgebra:-Norm(N_rv - N_Quantile, 1);

0.

(3)

Digits:= 30:

N_accurate:= CodeTools:-Usage(Statistics:-Quantile~(N01, S)):

memory used=0.89GiB, alloc change=0 bytes, cpu time=9.23s, real time=8.54s, gc time=1.02s



LinearAlgebra:-Norm(N_Quantile - N_accurate, 1);

0.114816126227654849290526416e-8

(4)

LinearAlgebra:-Norm(N_Newton - N_accurate, 1);

0.16152847737198934987933416e-9

(5)

14.61 / 5.32, 1.1e-9 / 1.6e-10;

2.74624060150375939849624060150, 6.87500000000000000000000000000

(6)

Conclusion: This particular Sample shows that using Newton's method (at Digits=20) gives about 6 times the accuracy while running at least 2 times as fast.






Download NormalInveseTest_mmcdara_reply.mw

@eslamelidy

You wrote "I want to solve tthe systems of diff equation what's the problem"... maybe you should be more specific and say exactly what the "problem" you are facing is.
I gave a look to your code, the first problem you should meet is related to the line R := ... : this line should generate an error message because you try to assign R an expression and that R is protected (R is a component of the package CodeGeneration, to see this write with(CodeGeneration);).

If you want to avoid thus first error you have 3 solutions:

  1. change the name of the variable R
  2. write with(CodeGeneration, Matlab); instead of with(CodeGeneration)
  3. do not load Codegeneration and write CodeGeneration:-Matlab instead of Matlab (bottom of your worksheet):


A second problem could  come from the Matlab conversion: not all the Maple's expressions can be translated into Matlab code.
A simple example among a lot of others:
restart:
with(CodeGeneration):
f := piecewise(x<0, -x, x):
Matlab(f);
 #observe the warning


So, could you explain precisely what "what's the problem" does mean to you?

Beyond all this, your worksheet is amazingly complex to read and thus to understand.
I think, and it was the purpose of my previous reply, that you would have advantage in simplifying its content (I gave you an example for the first ode but I'm not going to do the job for the 150 remaining ones)

@Carl Love

Here it is.

This new file confirms what I sent you previously.
Still NormInv doesn't work for probabilities 1-1e-7

In some sense it's not dramatic for I will retrieve Maple 2018 in ten days after my vacations.



restart:

Digits:= 20: #Changing this doesn't change the code; it's just for testing.



#Symbolic steps are only needed to create the numeric procedures, not

#needed to run them:

Ncdf:= unapply(int(exp(-x^2/2)/sqrt(2*Pi), x= -infinity..X), X);

Newton:= unapply(simplify(x-(Ncdf(x)-Q)/D(Ncdf)(x)), (x,Q));



#Purely numeric procedures:

NormInv_inner:= proc(Q, eps)

local z:= 0, z1;

   do  z1:= evalf(Newton(z,Q));  if abs(z1-z) < eps then return z1 fi;  z:= z1  od

end proc:



NormInv:= (Q::And(numeric, realcons, satisfies(Q-> 0 <= Q and Q <= 1)))->

   if Q > 1/2 then -thisproc(1-Q)

   elif Q = 0 then -infinity

   elif Digits <= evalhf(Digits) then evalhf(NormInv_inner(Q, DBL_EPSILON))

   else NormInv_inner(evalf(Q), 10.^(1-Digits))

   fi

:



proc (X) options operator, arrow; 1/2+(1/2)*erf((1/2)*2^(1/2)*X) end proc



proc (x, Q) options operator, arrow; -(1/2)*2^(1/2)*Pi^(1/2)*erf((1/2)*2^(1/2)*x)*exp((1/2)*x^2)+2^(1/2)*Pi^(1/2)*Q*exp((1/2)*x^2)+x-(1/2)*2^(1/2)*Pi^(1/2)*exp((1/2)*x^2) end proc

(1)

kernelopts(version)

`Maple 2015.2, APPLE UNIVERSAL OSX, Dec 20 2015, Build ID 1097895`

(2)

Seed:=randomize();

156606905209673

(3)

with(Statistics):

# This restricted probability range is chosen because the full range
# generates situations that do not end in Maple 2015

P := Sample(Uniform(0.4, 0.6), 10^4):


f := proc(P)
local n, q:
for n from 1 to numelems(P) do q := P[n]: NormInv(q) end do:
end proc:
CodeTools:-Usage(Quantile~(Normal(0, 1), P, numeric)):
CodeTools:-Usage(f(P)):

memory used=1.59GiB, alloc change=428.01MiB, cpu time=16.34s, real time=15.85s, gc time=1.25s

memory used=1.02GiB, alloc change=32.00MiB, cpu time=9.59s, real time=8.98s, gc time=917.58ms








Download NotSoFast_2015_2.mw

@Carl Love

Here are the perfomances of NormInv compared to Quantile: you'll see that NormInv is not a very fast alternative to Quantile.
So, maybe it's "hard to believe that any of these "magic coefficients" methods are generally better than this simple Newton's method" but the evidence seems in the numbers.
Maybe it's not for nothing that mathematicians are seeking for fast methods to estimate the normal quantiles (see the paper cited by Axel in the first reply)?



# This restricted probability range is chosen because the full range
# generates situations that do not end in Maple 2015

P := Sample(Uniform(0.4, 0.6), 10^4):


f := proc(P)
local n, q:
for n from 1 to numelems(P) do q := P[n]: NormInv(q) end do:
end proc:
CodeTools:-Usage(Quantile~(Normal(0, 1), P, numeric)):
CodeTools:-Usage(f(P)):


memory used=1.57GiB, alloc change=32.00MiB, cpu time=16.02s, real time=14.87s, gc time=1.62s

memory used=1.02GiB, alloc change=32.00MiB, cpu time=9.70s, real time=8.80s, gc time=1.29s








Download NotSoFast.mw

@Carl Love

Thanks.
I will test your code once my holidays are over (I will then have Maple 2018 and it doesn(t work in Maple 2015)

For the moment here are the "exact quantiles".

BTW, my post has followed a strange direction for its purpose was not really to find a fast method to estimate the inverse normal cdf, but rather to point a "mistak" inthis reference book that is Abramowitz & Stegun


restart:

Digits := 20:
P := [seq(1 - 10.^(-k), k=1..Digits)]:

print~(P, parse~(sprintf~("%2.5f", Statistics:-Quantile~(Normal(0, 1), P)))):

.90000000000000000000, 1.28155



.99000000000000000000, 2.32635



.99900000000000000000, 3.09023



.99990000000000000000, 3.71902



.99999000000000000000, 4.26489



.99999900000000000000, 4.75342



.99999990000000000000, 5.19934



.99999999000000000000, 5.61200



.99999999900000000000, 5.99781



.99999999990000000000, 6.36134



.99999999999000000000, 6.70602



.99999999999900000000, 7.03448



.99999999999990000000, 7.34880



.99999999999999000000, 7.65063



.99999999999999900000, 7.94135



.99999999999999990000, 8.22208



.99999999999999999000, 8.49379



.99999999999999999900, 8.75729



.99999999999999999990, 9.01327



.99999999999999999999, 9.26234

(1)






Download ExactQuantiles.mw

@vv

Your trick helps goinng a little bit further but not beyond P=0.998.

Could you please provide a result obtained with Maple 2018 or 2019?
For instance withe the sequence P=[seq(1-10^k, k=1..6)]

Thanks in advance




restart:

Digits:= 15: #Changing this doesn't change the code; it's just for testing.



#Symbolic steps are only needed to create the numeric procedures, not

#needed to run them:

Ncdf:= unapply(int(exp(-x^2/2)/sqrt(2*Pi), x= -infinity..X), X);

Newton:= unapply(simplify(x-(Ncdf(x)-Q)/D(Ncdf)(x)), (x,Q));



#Purely numeric procedures:

NormInv_inner:= proc(Q)

local z:= 0, z1;

   do  z1:= Newton(z,Q);  if abs(z1-z)<10^(-Digits+1) then return z1 fi;  z:= z1  od

end proc:



NormInv:= (Q::And(realcons, satisfies(Q-> 0 <= Q and Q <= 1)))->

   if Q > 1/2 then -thisproc(1-Q)

   elif Q=0 then -infinity

   elif Digits <= evalhf(Digits) then evalhf(NormInv_inner(Q))

   else NormInv_inner(evalf(Q))

   fi

:



proc (X) options operator, arrow; 1/2+(1/2)*erf((1/2)*2^(1/2)*X) end proc



proc (x, Q) options operator, arrow; -(1/2)*2^(1/2)*Pi^(1/2)*erf((1/2)*2^(1/2)*x)*exp((1/2)*x^2)+2^(1/2)*Pi^(1/2)*Q*exp((1/2)*x^2)+x-(1/2)*2^(1/2)*Pi^(1/2)*exp((1/2)*x^2) end proc

(1)

interface(version)

`Standard Worksheet Interface, Maple 2015.2, Mac OS X, December 21 2015 Build ID 1097895`

(2)

P := [seq(k/(k+1), k=100..1000, 100)]:

for n from 1 to numelems(P) do
  printf("%2d  %0.5f", n, P[n]);
  printf("   %2.5f", NormInv(P[n]));
  print():
end do;

 1  0.99010   2.33008





 2  0.99502   2.57755





 3  0.99668   2.71415





 4  0.99751   2.80784





 5  0.99800   2.87879





 6  0.99834

Warning,  computation interrupted








Download NewtonFails_2.mw

@Carl Love

Procedure NormInv fails do return a esult in a reasonable time for Q > 0.969:



restart:

Digits:= 15: #Changing this doesn't change the code; it's just for testing.



#Symbolic steps are only needed to create the numeric procedures, not

#needed to run them:

Ncdf:= unapply(int(exp(-x^2/2)/sqrt(2*Pi), x= -infinity..X), X);

Newton:= unapply(simplify(x-(Ncdf(x)-Q)/D(Ncdf)(x)), (x,Q));



#Purely numeric procedures:

NormInv_inner:= proc(Q)

local z:= 0, z1;

   do  z1:= Newton(z,Q);  if z1=z then return z1 fi;  z:= z1  od

end proc:



NormInv:= (Q::And(realcons, satisfies(Q-> 0 <= Q and Q <= 1)))->

   if Q > 1/2 then -thisproc(1-Q)

   elif Q=0 then -infinity

   elif Digits <= evalhf(Digits) then evalhf(NormInv_inner(Q))

   else NormInv_inner(evalf(Q))

   fi

:



proc (X) options operator, arrow; 1/2+(1/2)*erf((1/2)*2^(1/2)*X) end proc



proc (x, Q) options operator, arrow; -(1/2)*2^(1/2)*Pi^(1/2)*erf((1/2)*2^(1/2)*x)*exp((1/2)*x^2)+2^(1/2)*Pi^(1/2)*Q*exp((1/2)*x^2)+x-(1/2)*2^(1/2)*Pi^(1/2)*exp((1/2)*x^2) end proc

(1)

f := proc(P)
  local n:
  for n from 1 to numelems(P) do NormInv(P[n]) end do:
end proc:

with(Statistics):

P := Sample(Uniform(0.5, 1), 10^3):
CodeTools:-Usage(Quantile~(Normal(0, 1), P)):
CodeTools:-Usage(Quantile~(Normal(0, 1), P, numeric)):
CodeTools:-Usage(f(P)):

memory used=17.03MiB, alloc change=0 bytes, cpu time=304.00ms, real time=304.00ms, gc time=0ns

memory used=17.14MiB, alloc change=0 bytes, cpu time=312.00ms, real time=312.00ms, gc time=0ns

Warning,  computation interrupted



P := Statistics:-Sample(Uniform(0.5, 1), 10^1);

P := Vector[row](10, {(1) = .5814494501088662, (2) = .9192028848365151, (3) = .5837804651056354, (4) = .7511003077047363, (5) = .9996647395128597, (6) = .6777035756339407, (7) = .523538854774417, (8) = .6068302925603996, (9) = .6989195620513526, (10) = .6668340901901474}, datatype = float[8])

(2)

for n from 1 to 10 do
n;
NormInv(P[n])
end do;

1



.205602915707357559



2



1.39972985397027738



3



.211574416971719526



4



.677956326586950597



5



3.40135741509089939



6



Warning,  computation interrupted



NormInv(0.969)

Warning,  computation interrupted








Download NewtonFails.mw

@Axel Vogt

Thank you Axel, it's indeed a very interesting paper.



@mehdi jafari

You cannot have a set with elements 1, 1, 3, 3, 5, 6: in a set, each element is present only once.
So you can't do with sets what you did with lists.

@Carl Love

@Moh Huda

Given the title of the plots I guessed D[Cchemo] is the Chemo Dose (which is of no practical help)

More interesting, I found this open source for the paper: https://arxiv.org/pdf/1806.05790.pdf.
D[chemo] is indeed the "chemotherapeutic dose" and it seems (but I'm not sure otf that) it' could be defined by relation (7).

Nevertheless I wouldn't go any further on my side.

Moh: your write is "My question is how to get the first two figures below based on these information...", my answer is: "do what is described in the paper cite, all the stuff seems to be here".
If you are puzzled with the term s∞, it's defined below equation (10): "The case with constant immunotherapy (s(t) = s∞)".
Maybe you should read the paper more carefully?



@Daniel Skoog

Thank you

@Area51

Thanks for your reply.
This would not be the first time that an article has contained typos. If you are familiar with the subject revelopped in the article (I'm not and I just looked at this article very quickly), maybe you could try to verify there is no typo in the differential equations (for instance eq 47 comes from "combining eqs 26 and 46: is it right).
Given the content of the article, and if you are familiar enough with Maple, you could try to use the Physics package.
In case you will face problems, there are people here that are specialists of it and who could help you.


Need corrections and precisions:

  1. The differential equations in your introductory text differ from those in your worksheet:
    1. in the text it's written tau_0 and t0 in the worksheet (I suppose it's a typo in the later)
    2. in the text the 1st ode contains omega and the 2nd contains omega_m, while both of them contain omega in the worksheet.
      Text and worksheet disagree but, even if you code correctly the odes from the text, you will have a problem because the solutions you give in the text do not contain omega ???

  2. What are A, C_- and C_+ in the solution? Any constants?


In the worksheet above I replaced omega_m by omega in the solution you give and t0 by tau_0 in the each ode.
Next I checked if the solution you give was indeed a solution of the odes.
The answer is NO, unless A=0.




restart

sysode := [ 2*q*(3*q-1)*f1(tau)/tau^2+2*q*(diff(f1(tau), tau))/tau+diff(f1(tau), tau, tau)+(kappa^2+f2(tau))*(1+omega)*(tau/tau__0)^(-(3*(3+omega))*q) = 0, (54*q^3-30*q^2+4*q)*f1(tau)/tau^3+(24*q^2-4*q)*(diff(f1(tau), tau))/tau^2+11*q*(diff(f1(tau), tau, tau))/tau+diff(f1(tau), tau, tau, tau)-3*omega*(1+omega)*(kappa^2+f2(tau))*q*(tau/tau__0)^(-(3*(1+omega))*q)/tau = 0 ]:

print~(sysode):

2*q*(3*q-1)*f1(tau)/tau^2+2*q*(diff(f1(tau), tau))/tau+diff(diff(f1(tau), tau), tau)+(kappa^2+f2(tau))*(1+omega)*(tau/tau__0)^(-3*(3+omega)*q) = 0



(54*q^3-30*q^2+4*q)*f1(tau)/tau^3+(24*q^2-4*q)*(diff(f1(tau), tau))/tau^2+11*q*(diff(diff(f1(tau), tau), tau))/tau+diff(diff(diff(f1(tau), tau), tau), tau)-3*omega*(1+omega)*(kappa^2+f2(tau))*q*(tau/tau__0)^(-3*(1+omega)*q)/tau = 0

(1)

indets~(sysode, function);

[{diff(diff(f1(tau), tau), tau), diff(f1(tau), tau), f1(tau), f2(tau)}, {diff(diff(diff(f1(tau), tau), tau), tau), diff(diff(f1(tau), tau), tau), diff(f1(tau), tau), f1(tau), f2(tau)}]

(2)

AssumedSolution := [
  f2(tau) = -A*(69*q^2-25*q+2)/(1+omega)*tau__0^(-9*q)*(tau/tau__0)^(3*omega*q)-kappa^2,
  f1(tau) = C__p*tau^mu__p+C__m*tau^mu__m + A*tau__0^(-9*q+2)
]:
print~(AssumedSolution):

f2(tau) = -A*(69*q^2-25*q+2)*tau__0^(-9*q)*(tau/tau__0)^(3*omega*q)/(1+omega)-kappa^2



f1(tau) = C__p*tau^mu__p+C__m*tau^mu__m+A*tau__0^(-9*q+2)

(3)

AssumedMu := [
  mu__m = (-2*q+1-sqrt(-20*q^2+4*q+1))/2,
  mu__p = (-2*q+1+sqrt(-20*q^2+4*q+1))/2
]:
print~(AssumedMu):

mu__m = -q+1/2-(1/2)*(-20*q^2+4*q+1)^(1/2)



mu__p = -q+1/2+(1/2)*(-20*q^2+4*q+1)^(1/2)

(4)

test := eval(AssumedSolution, AssumedMu);

[f2(tau) = -A*(69*q^2-25*q+2)*tau__0^(-9*q)*(tau/tau__0)^(3*omega*q)/(1+omega)-kappa^2, f1(tau) = C__p*tau^(-q+1/2+(1/2)*(-20*q^2+4*q+1)^(1/2))+C__m*tau^(-q+1/2-(1/2)*(-20*q^2+4*q+1)^(1/2))+A*tau__0^(-9*q+2)]

(5)

eval(sysode, test):

simplify(%);

[A*(-69*tau__0^(-9*q)*(tau/tau__0)^(-9*q)*q^2*tau^2+25*tau__0^(-9*q)*(tau/tau__0)^(-9*q)*q*tau^2-2*tau__0^(-9*q)*(tau/tau__0)^(-9*q)*tau^2+6*tau__0^(-9*q+2)*q^2-2*tau__0^(-9*q+2)*q)/tau^2 = 0, A*q*(207*tau__0^(-9*q)*(tau/tau__0)^(-3*q)*omega*q^2*tau^2-75*omega*tau__0^(-9*q)*(tau/tau__0)^(-3*q)*q*tau^2+6*tau__0^(-9*q)*(tau/tau__0)^(-3*q)*omega*tau^2+54*tau__0^(-9*q+2)*q^2-30*tau__0^(-9*q+2)*q+4*tau__0^(-9*q+2))/tau^3 = 0]

(6)






Download question_2.mw

@Carl Love

Don't you think that what glcrawfo is looking for is just something like this ?



restart:

f := (t, N) -> Sum((-1)^n*Heaviside(t-n), n=1..N)

proc (t, N) options operator, arrow; Sum((-1)^n*Heaviside(t-n), n = 1 .. N) end proc

(1)

R := 20 : C := 0.01 : L := 10:

# choose N=2 for illustration

doe := (L*C*diff(x(t), t$2) + R*C*diff(x(t), t) + x(t)/C) = 200*f(t/3, 2);
value(doe)

.10*(diff(diff(x(t), t), t))+.20*(diff(x(t), t))+0.1e3*x(t) = -200*Heaviside(t-3)+200*Heaviside(t-6)

(2)

sol_exact := dsolve(value(doe), x(t));  #no need to fix the initial contitions here

x(t) = exp(-t)*sin(3*111^(1/2)*t)*_C2+exp(-t)*cos(3*111^(1/2)*t)*_C1-2*Heaviside(t-3)+(2/333)*111^(1/2)*Heaviside(t-3)*exp(-t+3)*sin(3*111^(1/2)*(t-3))+2*Heaviside(t-3)*exp(-t+3)*cos(3*111^(1/2)*(t-3))+2*Heaviside(t-6)-(2/333)*111^(1/2)*Heaviside(t-6)*exp(-t+6)*sin(3*111^(1/2)*(t-6))-2*Heaviside(t-6)*exp(-t+6)*cos(3*111^(1/2)*(t-6))

(3)

# numerical solution: here initial contitions are required


doe := (L*C*diff(x(t), t$2) + R*C*diff(x(t), t) + x(t)/C) = 200*f(t/3, 50):
sol_num := dsolve({value(doe),   x(0)=0, D(x)(0)=0  }, numeric, maxfun=10^6, method=rosenbrock, range=0..50);
#                              it's just an example

`[Length of output exceeds limit of 1000000]`

(4)

plots:-odeplot(sol_num, [t, x(t)], t=0..50, refine=2)








Download ode.mw

1 2 3 4 5 6 7 Last Page 1 of 31
