I use a personal licensed copy of Maple (Maple 2020.2).  In the "help about" dialog there is a clickable box titled "Reactivate License".  Does this imply that my license is not activated?  I have not had any issues with using the software.

Regards

Frank

[Moderator: removed image of help-about dialog showing purchase code]

Hi,

I have the following problem with plots in Maple 2020: I wanted to create several plots which should have the exact same size. I used the command size = [400,400] and Maple is creating a plot with that size, but Maple applies a white frame to my plots which does not have the same size in all cases (see the red mark of different length in the pictures below), so that the effective size differs, which is extremely ugly if you want to arrange several pictures in a document. So my question is

1.) How to remove this white frame, so that the efftictive picture size is actually 400x400?

2.) If 1.) is not possible, how can I adjust the frame so that it always has the same size?

My Code:

with(plots);
with(ColorTools);
with(plottools);
plot1 := inequal(0 <= y^3 + x^2, x = -5 .. 5, y = -5 .. 5, filledregions, color = blue, background = "Gainsboro", size = [400, 400]);
plot2 := plot(x = -5 .. 5, y = -5 .. 5, background = "Gainsboro");
ll := line([-3, 0], [3, 0]), color = blue, thickness = 5;
l := line([-3, 2], [5, 5]), color = blue, thickness = 2;
display(plot2, l, size = [400, 400]);

Thanks for your help.

Hello,

I have lists of points of different ranges that I want to plot on the same graph. I would not want to manually cut the list for the range I want to see (there are many lists) so I thought about the view option. But there seems to be a strange behaviour of pointplot combined with view:

restart;
with(plots);
pointplot([[0.1, 0.5], [0.7, 0.7]], view = [0 .. 1, 0 .. 0.1]);



I would like to assign the values of basis vectors which are calculated by PlanePlot. Is there anyone who knows how to use them or how to imitate the command?

PlanePlot(z+tan(-Pi/2+alph||29)*(x*sin(-Pi/2+gam||29)-y*cos(-Pi/2+gam||29))=0, [x,y,z],showbasis):
normal vector: <-.2497, .7343e-1, 1.>
equation of plane: -.2497*x+.7343e-1*y+1.*z = 0.
point on plane nearest origin: <-0., 0., 0.>
basis vectors: <.7106e-1, .9959, -.5539e-1>, <.9678, -.5539e-1, .2457>

It looks like as below:

restart;
line := x/100 - 1/2;
wave := cos(x / 5) * sin(x / 2); ## -1 <= wave <= 1
eq:= line - wave;
r1 := solve(line < -1); ## RealRange(-infinity,Open(-50))
r2 := solve(line > 1);  ## RealRange(Open(150),infinity)
## There are 27 solutions in RealRange(-50,150)

I searched Questions.  Found many solutions.  The only one that seems to work is Student[Calculus1]:-Roots()

Is there another way to do this?

I am trying to solve a system of polynomial equations (with rational number coefficients). For this I am computing its Gröbner basis using the F4 algorithm implemented in Maple. (`Groebner[Basis]`).

As far as I understand it, the algorithms solves the problem modulo one or more prime number and later reconstructs the full (rational number) solution. Usually it only takes a handfull of primes. But in my case it by now solved the problem successfully modulo about ~300 different primes, each time doing exactly the same computation (according to the log files running with `infolevel[GroebnerBasis]:=5`).

Could somebody enlighten me what this means? In particular, can I interpret this as indication that the system of equations does have or does not have a solution?

  • My system of equations is rather large. Each individual solve modulo a prime takes half an hour on a powerful workstation pc. Other computeralgebra systems without Faugère's algorithms cant solve it at all.
  • (part of) the output can be found here: https://gist.github.com/krox/484252f075eb19edd0ac865099a564ba . The curious thing to me is that each solve behaves exactly the same. So why is maple repeating it with different primes over and over again?

Hi there, I just wanna solve a nonlinear diff equation for a 2 variables function phi.

Boundary conditions :

  1. at the wall over NACA 0012 : the derivatives wrt x & y are null
  2. for y at infinity : the derivatives wrt x & y are null

How to deal with curved body unlike the flat plate ?

Thanks for your help in advance!

This worksheet displays an ellipsoid internally tangent to the four sides of a tetrahedron.

The tetrahedron is a special case: it has a horizontal base with vertices A,B and C and its fourth vertex E is on the z axis.

However I have failed when trying to display an internally tangent ellipsoid in any other tetrahedron.

Will any tetrahedron support one or more internally tangent ellipsoids?

If so, are there conditions restricting the location of the mutual points of tangency?

Ellipsoid_in_a_tetrahedron.mw

Hello,



When I try to get the magnitude of the transfer function in the uploaded file, I get this error:

Error, invalid input: `simpl/abs` expects its 1st argument, a1, to be of type algebraic, but received [0.15000e8/(-0.2137457857e-6*f^2+(2.909554620*I)*f-(0.1565896548e-13*I)*f^3+0.152600e8)]


How do I get the magnitude and phase of this transfer function so I can plot it as a function of frequency, f?  If you can show me how to plot it, that would help a lot as well.



Thank you,

Maple Worksheet - Error

Failed to load the worksheet /maplenet/convert/temp.mw .


Download temp.mw

In general, the Graph6 format is a graph format supported by major math software, so I used it as a transitional format.

with(GraphTheory):
g:=Graph(Matrix(42, 42, [[0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1], [0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 1, 0, 1, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1], [0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 1], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 1], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0], [0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1], [1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0], [1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0], [1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0], [1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0], [0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 1, 0, 0, 0, 0, 0, 0, 1, 0], [0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 1, 0, 0, 1, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 1, 0, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 0, 0, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 0, 1, 0, 1, 0, 1, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 1, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 1, 1, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 0], [0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 0], [0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 1, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0]])):
s:=ConvertGraph(g,'graph6')






When I try to read this graph6 string with Mathematica or Sagemath, unfortunately there are unrecognized problems.  Later, I found that when copying, there would be missing the backslash .

"ihChWC@?gE_@?@?A_@g?@??C??j?@l??E??Ao?? (miss \ when copy)???m??@I??DF??E`O??GM??@?g??S@o?@g@O??G?w??C?I??D?@o?@g?D???_?M??@??I??D??FK?E_?@Q??G??N??@???CPCOaGa????"

I'm trying to figure out this problem of copying strings.









Dear Fellows, greetings

I am solving a system of equations under some assumptions and those assupmtions are a must to impose. However maple fails to apply those while solving the equations. For example solution 4 gives b=c as a solution but in assumtion it is clrealy mentioned that b<>c. Kindly guide me what mistake am I making in the code.

System_problem.mw

Hi

I have a list of records :

S := [`206` = Record(mu = 508.001018040, sigma = 125.002863204708), `4` = Record(mu = 1008.001018040, sigma = 167.707232430134), `2` = Record(mu = 1208.001018040, sigma = 141.512246146314), `5` = Record(mu = 808.001018040, sigma = 117.156800098735)]

How can I extract from S the mu and sd corresponding to a number.

eg input 2 get 1208.001018040,141.512246146314

like this:  rhs(S[3]):-mu, rhs(S[3]):-sigma, (I know from inpection 2 occurs in the 3rd slot but assume i don't know where it occurs). I tried using Search...


Suppose we have an unknown parametric function like g(x). We do not know the exact form but we know that g(x) is increasing and concave. Also, we define h(x) = g(x)*f(x) where we know the exact form of f(x) like f(x)=2x+5. Here, I want to investigate if the function h(x) is concave or not. How is it possible to do this?



Thanks

In this worksheet the solve command almost immediately gives up and DirectSearch[SolveEquations] is erratic.

For some triangle/inellipse points of tangency the latter provides a nonsense answer and for others it produces an almost correct solution.

Is there a set of conditions which determine the possibility of an inellipse within a triangle?

Inellipse.mw

A responder will have to establish a connection to the DirectSearch package.
