Hi MaplePrimes,

another_recursive_sequence.mw

another_recursive_sequence.pdf

These two files have the same content.  One is a .pdf and the other is a Maple Worksheet.  I explore integer sequences of the form -

a(r) = c*a(r-1)+d*a(r-2) with a(1) and a(2) given.

Some of these sequences are in (the Online Encyclopedia of Integer Sequences) OEIS.org and some are not.  If we restrict c to 1 and assume that a(1)=1 and a(2) = 2 we have the parameter d remaining.  See additional webpage -

https://sites.google.com/site/recrusivefunction/

Let me know if you like the code.

Regards,

Matt



As you can see this app performs the trace of a given path r (t), then locate the position vector in a specific time. It also graphs the velocity vector, acceleration, Tangential and Normal unit vectors, along with the Binormal. Very good app developed entirely in Maple for our engineering students.

Plot_of_Position_Vector_UPDATED.mw

https://youtu.be/OzAwShHHXq8

Lenin Araujo Castillo

Ambassador of Maple

I'm back from presenting work in the "23rd Conference on Applications of Computer Algebra -2017" . It was a very interesting event. This fifth presentation, about "The Appell doubly hypergeometric functions", describes a very recent project I've been working at Maple, i.e. the very first complete computational implementation of the Appell doubly hypergeometric functions. This work appeared in Maple 2017. These functions have a tremendous potential in that, at the same time, they have a myriad of properties, and include as particular cases most of the existing mathematical language, and so they have obvious applications in integration, differential equations, and applied mathematics all around. I think these will be the functions of this XXI century, analogously to what happened with hypergeometric functions in the previous century.

At the end, there is a link to the presentation worksheet, with which one could open the sections and reproduce the presentation examples.


The four double-hypergeometric Appell functions,

a complete implementation in a computer algebra system



Edgardo S. Cheb-Terrab

Physics, Differential Equations and Mathematical Functions, Maplesoft



Abstract:
The four multi-parameter Appell functions, AppellF1 , AppellF2 , AppellF3  and AppellF4  are doubly hypergeometric functions that include as particular cases the 2F1 hypergeometric  and some cases of the MeijerG  function, and with them most of the known functions of mathematical physics. Appell functions have been popping up with increasing frequency in applications in quantum mechanics, molecular physics, and general relativity. In this talk, a full implementation of these functions in the Maple computer algebra system, including, for the first time, their numerical evaluation over the whole complex plane, is presented, with details about the symbolic and numerical strategies used.

Appell Functions (symbolic)





The main references:

•

P. Appel, J.Kamke de Feriet, "Fonctions hypergeometriques et Hyperspheriques", 1926

•

H. Srivastava, P.W. Karlsson, "Multiple Gaussian Hypergeometric Series", 1985

•

24 papers in the literature, ranging from 1882 to 2015



Definition and Symmetries



Polynomial and Singular Cases



Single Power Series with Hypergeometric Coefficients



Analytic Extension from the Appell Series to the Appell Functions



Euler-Type and Contiguity Identities



Appell Differential Equations



Putting all together



Problem: some formulas in the literature are wrong or miss the conditions indicating when are they valid (exchange with the Mathematics director of the DLMF - NIST)



Appell Functions (numeric)





Goals



•

Compute these Appell functions over the whole complex plane

•

Considering that this is a research problem, implement different methods and flexible optional arguments to allow for:

a) comparison between methods (both performance and correctness),

b) investigation of a single method in different circumstances.

•

Develop a computational structure that can be reused with other special functions (abstract code and provide the main options), and that could also be translated to C (so: only one numerical implementation, not 100 special function numerical implementations)

Limitation: the Maple original evalf command does not accept optional arguments



The cost of numerically evaluating an Appell function



•

If it is a special hypergeometric case, then between 1 to 2 hypergeometric functions

•

Next simplest case (series/recurrence below) 3 to 4 hypergeometric functions plus adding somewhat large formulas that involve only arithmetic operations up to 20,000 times (frequently less than 100 times)

•

Next simplest case: the formulas themselves are power series with hypergeometric function coefficients; these cases frequently converge rapidly but may involve the numerical evaluation of up to hundreds of hypergeometric functions to get the value of a single Appell function.



Strategy for the numerical evaluation of Appell functions (or other functions ...)





The numerical evaluation flows orderly according to:

1) check whether it is a singular case

2) check whether it is a special value

3) compute the value using a series derived from a recurrence related to the underlying ODE

4) perform an sum using an infinite sum formula, checking for convergence

5) perform the numerical integration of the ODE underlying the given Appell function

6) perform a sequence of concatenated Taylor series expansions

Examples



Series/recurrence



Numerical integration of an underlying differential equation (ODEs and dsolve/numeric)



Concatenated Taylor series expansions covering the whole complex plane



Subproducts



Improvements in the numerical evaluation of hypergeometric functions



Evalf: an organized structure to implement the numerical evaluation of special functions in general



To be done






Download Appell_Functions.mw
Download Appell_Functions.pdf

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

I'm back from presenting work in the "23rd Conference on Applications of Computer Algebra -2017" . It was a very interesting event. This third presentation, about "Computer Algebra in Theoretical Physics", describes the Physics project at Maplesoft, also my first research project at University, that evolved into the now well-known Maple Physics package. This is a unique piece of software and perhaps the project I most enjoy working.

At the end, there is a link to the presentation worksheet, with which one could open the sections and reproduce the presentation examples.






Computer Algebra in Theoretical Physics



Edgardo S. Cheb-Terrab

Physics, Differential Equations and Mathematical Functions, Maplesoft



Abstract:



Generally speaking, physicists still experience that computing with paper and pencil is in most cases simpler than computing on a Computer Algebra worksheet. On the other hand, recent developments in the Maple system have implemented most of the mathematical objects and mathematics used in theoretical physics computations, and have dramatically approximated the notation used in the computer to the one used with paper and pencil, diminishing the learning gap and computer-syntax distraction to a strict minimum.



In this talk, the Physics project at Maplesoft is presented and the resulting Physics package is illustrated by tackling problems in classical and quantum mechanics, using tensor and Dirac's Bra-Ket notation, general relativity, including the equivalence problem, and classical field theory, deriving field equations using variational principles.









... and why computer algebra?



We can concentrate more on the ideas instead of on the algebraic manipulations



We can extend results with ease



We can explore the mathematics surrounding a problem



We can share results in a reproducible way



Representation issues that were preventing the use of computer algebra in Physics



Classical Mechanics



*Inertia tensor for a triatomic molecule



Quantum mechanics



*The quantum operator components of  `#mover(mi("L",mathcolor = "olive"),mo("→",fontstyle = "italic"))` satisfy "[L[j],L[k]][-]=i `ε`[j,k,m] L[m]"



*Unitary Operators in Quantum Mechanics



*Eigenvalues of an unitary operator and exponential of Hermitian operators



*Properties of unitary operators





Consider two set of kets " | a[n] >" and "| b[n] >", each of them constituting a complete orthonormal basis of the same space.

*Verify that "U=(&sum;) | b[k] >< a[k] |" , maps one basis to the other, i.e.: "| b[n] >=U | a[n] >"



*Show that "U=(&sum;) | b[k] > < a[k] | "is unitary



*Show that the matrix elements of U in the "| a[n] >" and  "| b[n] >" basis are equal



Show that A and `&Ascr;` = U*A*`#msup(mi("U"),mo("&dagger;"))`have the same spectrum (eigenvalues)



Schrödinger equation and unitary transform



Translation operators using Dirac notation



*Quantization of the energy of a particle in a magnetic field



Classical Field Theory



The field equations for the lambda*Phi^4 model



*Maxwell equations departing from the 4-dimensional Action for Electrodynamics



*The Gross-Pitaevskii field equations for a quantum system of identical particles



General Relativity



Exact Solutions to Einstein's Equations  Lambda*g[mu, nu]+G[mu, nu] = 8*Pi*T[mu, nu]



*"Physical Review D" 87, 044053 (2013)



The Equivalence problem between two metrics



*On the 3+1 split of the 4D Einstein equations



Tetrads and Weyl scalars in canonical form










Download Physics.mw

Download Physics.pdf

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

I'm back from presenting work in the "23rd Conference on Applications of Computer Algebra - 2017" . It was a very interesting event. This second presentation, about "Differential algebra with mathematical functions, symbolic powers and anticommutative variables", describes a project I started working in 1997 and that is at the root of Maple's dsolve and pdsolve performance with systems of equations. It is a unique approach. Not yet emulated in any other computer algebra system.

At the end, there is a link to the presentation worksheet, with which one could open the sections and reproduce the presentation examples.


Differential algebra with mathematical functions,

symbolic powers and anticommutative variables



Edgardo S. Cheb-Terrab

Physics, Differential Equations and Mathematical Functions, Maplesoft



Abstract:
Computer algebra implementations of Differential Algebra typically require that the systems of equations to be tackled be rational in the independent and dependent variables and their partial derivatives, and of course that A*B = A*B, everything is commutative.



It is possible, however, to extend this computational domain and apply Differential Algebra techniques to systems of equations that involve arbitrary compositions of mathematical functions (elementary or special), fractional and symbolic powers, as well as anticommutative variables and functions. This is the subject of this presentation, with examples of the implementation of these ideas in the Maple computer algebra system and its ODE and PDE solvers.





restartwith(PDEtools); interface(imaginaryunit = i)

sys := [diff(xi(x, y), y, y) = 0, -6*(diff(xi(x, y), y))*y+diff(eta(x, y), y, y)-2*(diff(xi(x, y), x, y)) = 0, -12*(diff(xi(x, y), y))*a^2*y-9*(diff(xi(x, y), y))*a*y^2-3*(diff(xi(x, y), y))*b-3*(diff(xi(x, y), x))*y-3*eta(x, y)+2*(diff(eta(x, y), x, y))-(diff(xi(x, y), x, x)) = 0, -8*(diff(xi(x, y), x))*a^2*y-6*(diff(xi(x, y), x))*a*y^2+4*(diff(eta(x, y), y))*a^2*y+3*(diff(eta(x, y), y))*a*y^2-4*eta(x, y)*a^2-6*eta(x, y)*a*y-2*(diff(xi(x, y), x))*b+(diff(eta(x, y), y))*b-3*(diff(eta(x, y), x))*y+diff(eta(x, y), x, x) = 0]



declare((xi, eta)(x, y))

xi(x, y)*`will now be displayed as`*xi



eta(x, y)*`will now be displayed as`*eta

(1)

for eq in sys do eq end do

diff(diff(xi(x, y), y), y) = 0



-6*(diff(xi(x, y), y))*y+diff(diff(eta(x, y), y), y)-2*(diff(diff(xi(x, y), x), y)) = 0



-12*(diff(xi(x, y), y))*a^2*y-9*(diff(xi(x, y), y))*a*y^2-3*(diff(xi(x, y), y))*b-3*(diff(xi(x, y), x))*y-3*eta(x, y)+2*(diff(diff(eta(x, y), x), y))-(diff(diff(xi(x, y), x), x)) = 0



-8*(diff(xi(x, y), x))*a^2*y-6*(diff(xi(x, y), x))*a*y^2+4*(diff(eta(x, y), y))*a^2*y+3*(diff(eta(x, y), y))*a*y^2-4*eta(x, y)*a^2-6*eta(x, y)*a*y-2*(diff(xi(x, y), x))*b+(diff(eta(x, y), y))*b-3*(diff(eta(x, y), x))*y+diff(diff(eta(x, y), x), x) = 0

(2)

casesplit(sys)

`casesplit/ans`([eta(x, y) = 0, diff(xi(x, y), x) = 0, diff(xi(x, y), y) = 0], [])

(3)

NULL

Differential polynomial forms for mathematical functions (basic)



Differential polynomial forms for compositions of mathematical functions



Generalization to many variables



Arbitrary functions of algebraic expressions



Examples of the use of this extension to include mathematical functions



Differential Algebra with anticommutative variables






Download DifferentialAlgebra.mw

Download DifferentialAlgebra.pdf

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft



I'm back from presenting work in the "23rd Conference on Applications of Computer Algebra - 2017" . It was a very interesting event. This first presentation, about "Active Learning in High-School Mathematics using Interactive Interfaces", describes a project I started working 23 years ago, which I believe will be part of the future in one or another form. This is work actually not related to my work at Maplesoft.

At the end, there is a link to the presentation worksheet, with which one could open the sections and reproduce the presentation examples.




Active learning in High-School mathematics using Interactive Interfaces



Edgardo S. Cheb-Terrab

Physics, Differential Equations and Mathematical Functions, Maplesoft



Abstract:


The key idea in this project is to learn through exploration using a web of user-friendly Highly Interactive Graphical Interfaces (HIGI). The HIGIs, structured as trees of interlinked windows, present concepts using a minimal amount of text while maximizing the possibility of visual and analytic exploration. These interfaces run computer algebra software in the background. Assessment tools are integrated into the learning experience within the general conceptual map, the Navigator. This Navigator offers students self-assessment tools and full access to the logical sequencing of course concepts, helping them to identify any gaps in their knowledge and to launch the corresponding learning interfaces. An interactive online set of HIGIS of this kind can be used at school, at home, in distance education, and both individually and in a group.





Computer algebra interfaces for High-School students of "Colegio de Aplicação"  (UERJ/1994)



Motivation





When we are the average high-school student facing mathematics, we tend to feel



•

Bored, fragmentarily taking notes, listening to a teacher for 50 or more minutes

•

Anguished because we do not understand some math topics (too many gaps accumulated)

•

Powerless because we don't know what to do to understand (don't have any instant-tutor to ask questions and without being judged for having accumulated gaps)

•

Stressed by the upcoming exams where the lack of understanding may become evident



Computer algebra environments can help in addressing these issues.





•

Be as active as it can get while learning at our own pace.

•

Explore at high speed and without feeling judged. There is space for curiosity with no computational cost.

•

Feel empowered by success. That leads to understanding.

•

Possibility for making of learning a social experience.



Interactive interfaces







Interactive interfaces do not replace the teacher - human learning is an emotional process. A good teacher leading good active learning is a positive experience a student will never forget





Not every computer interface is a valuable resource, at all. It is the set of pedagogical ideas implemented that makes an interface valuable (the same happens with textbooks)





A course on high school mathematics using interactive interfaces - the Edukanet project





–

Brazilian and Canadian students/programmers were invited to participate - 7 people worked in the project.



–

Some funding provided by the Brazilian Research agency CNPq.

Tasks:

-Develop a framework to develop the interfaces covering the last 3 years of high school mathematics (following the main math textbook used in public schools in Brazil)

- Design documents for the interfaces according to given pedagogical guidelines.

- Create prototypes of Interactive interfaces, running Maple on background, according to design document and specified layout (allow for everybody's input/changes).



The pedagogical guidelines for interactive interfaces



The Math-contents design documents for each chapter



Example: complex numbers



Each math topic:  a interactive interrelated interfaces (windows)





For each topic of high-school mathematics (chapter of a textbook), develop a tree of interactive interfaces (applets) related to the topic (main) and subtopics



Example: Functions



•

Main window



•

Analysis window

•



•

Parity window

•

Visualization of function's parity

•

Step-by-Step solution window

The Navigator: a window with a tile per math topic







•

Click the topic-tile to launch a smaller window, topic-specific, map of interrelated sub-topic tiles, that indicates the logical sequence for the sub-topics, and from where one could launch the corresponding sub-topic interactive interface.

•

This topic-specific smaller window allows for identifying the pre-requisites and gaps in understanding, launching the corresponding interfaces to fill the gaps, and tracking the level of familiarity with a topic.











The framework to create the interfaces: a version of NetBeans on steroids ...



Complementary classroom activity on a computer algebra worksheet





This course is organized as a guided experience, 2 hours per day during five days, on learning the basics of the Maple language, and on using it to formulate algebraic computations we do with paper and pencil in high school and 1st year of undergraduate science courses.



Explore. Having success doesn't matter, using your curiosity as a compass does - things can be done in so many different ways. Have full permission to fail. Share your insights. All questions are valid even if to the side. Computer algebra can transform the learning of mathematics into interesting understanding, success and fun.

1. Arithmetic operations and elementary functions



2. Algebraic Expressions, Equations and Functions



3. Limits, Derivatives, Sums, Products, Integrals, Differential Equations



4. Algebraic manipulation: simplify, factorize, expand



5. Matrices (Linear Algebra)





Advanced students: guiding them to program mathematical concepts on a computer algebra worksheet



Status of the project





Prototypes of interfaces built cover:



•

Natural numbers

•

Functions

•

Integer numbers

•

Rational numbers

•

Absolute value

•

Logarithms

•

Numerical sequences

•

Trigonometry

•

Matrices

•

Determinants

•

Linear systems

•

Limits

•

Derivatives

•

Derivative of the inverse function

•

The point in Cartesian coordinates

•

The line

•

The circle

•

The ellipse

•

The parabole

•

The hyperbole

•

The conics

More recent computer algebra frameworks: Maple Mobius for online courses and automated evaluation








Download Computer_Algebra_in_Education.mw

Download Computer_Algebra_in_Education.pdf

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

The representation of the tangent plane in the form of a square with a given length of the side at any point on the surface.

The equation of the tangent plane to the surface at a given point is obtained from the condition that the tangent plane is perpendicular to the normal vector. With the aid of any auxiliary point not lying on this normal to the surface, we define the direction on the tangent plane. From the given point in this direction, we lay off segments equal to half the length of the side of our square and with the help of these segments we construct the square itself, lying on the tangent plane with the center at a given point.

An examples of constructing tangent planes at points of the same intersection line for two surfaces.
Tangent_plane.mw

This app is used to study the behavior of water in its different properties besides air. Also included is the study of the fluids in the state of rest ie the pressure generated on a flat surface. Integral developed in Maple for the community of users in space to the civil engineers.

App_for_fluids_in_flat_state_of_rest.mw

Lenin Araujo Castillo

Ambassador of Maple



We have just released the 3rd edition of the Mathematics Survival Kit – Maple Edition.

The Math Survival Kit helps students get unstuck when they are stuck. Sometimes students are prevented from solving a problem, not because they haven’t understood the new concept, but because they forget how to do one of the steps, like completely the square, or dealing with log properties.  That’s where this interactive e- book comes in. It gives students the opportunity to review exactly the concept or technique they are stuck on, work through an example, practice as much (or as little) as they want using randomly generated, automatically graded questions on that exact topic, and then continue with their homework.

This book covers over 150 topics known to cause students grief, from dividing fractions to integration by parts. This 3rd edition contains 31 additional topics, deepening the coverage of mathematical topics at every level, from pre-high school to university.

See the Mathematics Survival Kit for more information about this updated e-book, including the complete list of topics.

eithne

This post is the answer to this question.

The procedure named  IntOverDomain  finds a double integral over an arbitrary domain bounded by a non-selfintersecting piecewise smooth curve. The code of the procedure uses the well-known Green's theorem.

Each section in the border should be specified by a list in the following formats :
1. If a section is given parametrically, then  [[f(t), g(t)], t=t1..t2]
2. If several consecutive sections of the border or the entire border is a broken line, then it is sufficient to set vertices of this broken line  [ [x1,y1], [x2,y2], .., [xn,yn] ] (for the entire border should be  [xn,yn]=[x1,y1] ).

Required parameters of the procedure:  f  is an expression in variables  x  and  y , L  is the list of all the sections. The sublists of the list  L  must follow in the positive direction (counterclockwise).

The code of the procedure:

restart;
IntOverDomain := proc(f, L)
local n, i, j, m, yk, yb, xk, xb, Q, p, P, var;
n:=nops(L);
Q:=int(f,x);
for i from 1 to n do
if type(L[i], listlist(algebraic)) then
m:=nops(L[i]);
for j from 1 to m-1 do
yk:=L[i,j+1,2]-L[i,j,2]; yb:=L[i,j,2];
xk:=L[i,j+1,1]-L[i,j,1]; xb:=L[i,j,1];
p[j]:=int(eval(Q*yk,[y=yk*t+yb,x=xk*t+xb]),t=0..1);
od;
P[i]:=add(p[j],j=1..m-1) else
var := lhs(L[i, 2]);
P[i]:=int(eval(Q*diff(L[i,1,2],var),[x=L[i,1,1],y=L[i,1,2]]),L[i,2]) fi;
od;
add(P[i], i = 1 .. n);
end proc:



Examples of use.

1. In the first example, we integrate over a quadrilateral:

with(plottools): with(plots):
f:=x^2+y^2:
display(polygon([[0,0],[3,0],[0,3],[1,1]], color="LightBlue"));
# Visualization of the domain of integration
IntOverDomain(x^2+y^2, [[[0,0],[3,0],[0,3],[1,1],[0,0]]]);  # The value of integral



2. In the second example, some sections of the boundary of the domain are curved lines:

display(inequal({{y<=sqrt(x),y>=sin(Pi*x/3)/2,y<=3-x}, {y>=-2*x+3,y>=sqrt(x),y<=3-x}}, x=0..3,y=0..3, color="LightGreen", nolines), plot([[t,sqrt(t),t=0..1],[t,-2*t+3,t=0..1],[t,3-t,t=0..3],[t,sin(Pi*t/3)/2,t=0..3]], color=black, thickness=2));
f:=x^2+y^2: L:=[[[t,sin(Pi*t/3)/2],t=0..3],[[3,0],[0,3],[1,1]], [[t,sqrt(t)],t=1..0]]:
IntOverDomain(f, L);



3. If  f=1  then the procedure returns the area of the domain:

IntOverDomain(1, L);  # The area of the above domain
evalf(%);



IntOverDomain.mw

Edit.

This app shows the calculation of the final speed of a body after it made contact with a variable force; Taking as reference the initial velocity, mass and graph of the variation of F as a function of time. That is, given the variable forces represented by the lines in the time intervals, we will show the equation of momentum and momentum; With their respective values, followed by their response.

Momentum_with_two_variable_force.mw

https://www.youtube.com/watch?v=2xWkF7JhkpI

Lenin Araujo C.

Ambassador of Maple















Physics





Maple provides a state-of-the-art environment for algebraic and tensorial computations in Physics, with emphasis on ensuring that the computational experience is as natural as possible.



The theme of the Physics project for Maple 2017 has been the consolidation of the functionality introduced in previous releases, together with significant enhancements and new functionality in General Relativity, in connection with classification of solutions to Einstein's equations and tensor representations to work in an embedded 3D curved space - a new ThreePlusOne  package. This package is relevant in numerical relativity and a Hamiltonian formulation of gravity. The developments also include first steps in connection with computational representations for all the objects entering the Standard Model in particle physics.

Classification of solutions to Einstein's equations and the Tetrads package



In Maple 2016, the digitizing of the database of solutions to Einstein's equations  was finished, added to the standard Maple library, with all the metrics from "Stephani, H.; Kramer, D.; MacCallum, M.; Hoenselaers, C.; and Herlt, E., Exact Solutions to Einstein's Field Equations". These metrics can be loaded to work with them, or change them, or searched using g_  (the Physics command representing the spacetime metric that also sets the metric to your choice in one go) or using the command DifferentialGeometry:-Library:-MetricSearch .


In Maple 2017, the Physics:-Tetrads  package has been vastly improved and extended, now including new commands like PetrovType  and SegreType  to classify these metrics, and the TransformTetrad  now has an option canonicalform to automatically derive a transformation and put the tetrad in canonical form (reorientation of the axis of the local system of references), a relevant step in resolving the equivalence between two metrics.

Examples



Petrov and Segre types, tetrads in canonical form



Equivalence for Schwarzschild metric (spherical and Kruskal coordinates)



Formulation of the problem (remove mixed coordinates)



Solving the Equivalence



The ThreePlusOne (3 + 1) new Maple 2017 Physics package



ThreePlusOne , is a package to cast Einstein's equations in a 3+1 form, that is, representing spacetime as a stack of nonintersecting 3-hypersurfaces Σ. This 3+1 description is key in the Hamiltonian formulation of gravity as well as in the study of gravitational waves, black holes, neutron stars, and in general to study the evolution of physical system in general relativity by running numerical simulations as traditional initial value (Cauchy) problems. ThreePlusOne includes computational representations for the spatial metric gamma[i, j] that is induced by g[mu, nu] on the 3-dimensional hypersurfaces, and the related covariant derivative, Christoffel symbols and Ricci and Riemann tensors, the Lapse, Shift, Unit normal and Time vectors and Extrinsic curvature related to the ADM equations.



The following is a list of the available commands:



ADMEquations

Christoffel3

D3_

ExtrinsicCurvature

gamma3_

Lapse

Ricci3

Riemann3

Shift

TimeVector

UnitNormalVector





The other four related new Physics  commands:



•

Decompose , to decompose 4D tensorial expressions (free and/or contracted indices) into the space and time parts.

•

gamma_ , representing the three-dimensional metric tensor, with which the element of spatial distance is defined as  `#mrow(msup(mi("dl"),mrow(mo("&InvisibleTimes;"),mn("2"))),mo("&equals;"),msub(mi("&gamma;",fontstyle = "normal"),mrow(mi("i"),mo("&comma;"),mi("j"))),mo("&InvisibleTimes;"),msup(mi("dx"),mi("i")),mo("&InvisibleTimes;"),msup(mi("dx"),mi("j")))`.

•

Redefine , to redefine the coordinates and the spacetime metric according to changes in the signature from any of the four possible signatures(− + + +), (+ − − −), (+ + + −) and ((− + + +) to any of the other ones.

•

EnergyMomentum , is a computational representation for the energy-momentum tensor entering Einstein's equations as well as their 3+1 form, the ADMEquations .



Examples



restart; with(Physics); Setup(coordinatesystems = cartesian)

`Default differentiation variables for d_, D_ and dAlembertian are: `*{X = (x, y, z, t)}



`Systems of spacetime Coordinates are: `*{X = (x, y, z, t)}



[coordinatesystems = {X}]

(2.1.1)

with(ThreePlusOne)

`Setting lowercaselatin_is letters to represent space indices `



0, "%1 is not a command in the %2 package", ThreePlusOne, Physics



`Changing the signature of spacetime from `(`- - - +`)*` to `(`+ + + -`)*` in order to match the signature customarily used in the ADM formalism`



[ADMEquations, Christoffel3, D3_, ExtrinsicCurvature, Lapse, Ricci3, Riemann3, Shift, TimeVector, UnitNormalVector, gamma3_]

(2.1.2)

Note the different color for gamma[mu, nu], now a 4D tensor representing the metric of a generic 3-dimensional hypersurface induced by the 4D spacetime metric g[mu, nu]. All the ThreePlusOne tensors are displayed in black to distinguish them of the corresponding 4D or 3D tensors. The particular hypersurface gamma[mu, nu] operates is parameterized by the Lapse  alpha and the Shift  beta[mu].

The induced metric gamma[mu, nu]is defined in terms of the UnitNormalVector  n[mu] and the 4D metric g[mu, nu] as

gamma3_[definition]

Physics:-ThreePlusOne:-gamma3_[mu, nu] = Physics:-ThreePlusOne:-UnitNormalVector[mu]*Physics:-ThreePlusOne:-UnitNormalVector[nu]+Physics:-g_[mu, nu]

(2.1.3)

where n[mu] is defined in terms of the Lapse  alpha and the derivative of a scalar function t that can be interpreted as a global time function

UnitNormalVector[definition]

Physics:-ThreePlusOne:-UnitNormalVector[mu] = -Physics:-ThreePlusOne:-Lapse*Physics:-D_[mu](t)

(2.1.4)

The TimeVector  is defined in terms of the Lapse  alpha and the Shift  beta[mu] and this vector  n[mu] as

TimeVector[definition]

Physics:-ThreePlusOne:-TimeVector[mu] = Physics:-ThreePlusOne:-Lapse*Physics:-ThreePlusOne:-UnitNormalVector[mu]+Physics:-ThreePlusOne:-Shift[mu]

(2.1.5)

The ExtrinsicCurvature  is defined in terms of the LieDerivative  of  gamma[mu, nu]

ExtrinsicCurvature[definition]

Physics:-ThreePlusOne:-ExtrinsicCurvature[mu, nu] = -(1/2)*Physics:-LieDerivative[Physics:-ThreePlusOne:-UnitNormalVector](Physics:-ThreePlusOne:-gamma3_[mu, nu])

(2.1.6)

The metric gamma[mu, nu]is also a projection tensor in that it projects 4D tensors into the 3D hypersurface Σ. The definition for any 4D tensor that is also a 3D tensor in Σ, can thus be written directly by contracting their indices with gamma[mu, nu]. In the case of Christoffel3 , Ricci3  and Riemann3,  these tensors can be defined by replacing the 4D metric g[mu, nu] by gamma[mu, nu] and the 4D Christoffel symbols GAMMA[mu, nu, alpha] by the ThreePlusOne GAMMA[mu, nu, alpha] in the definitions of the corresponding 4D tensors. So, for instance

Christoffel3[definition]

Physics:-ThreePlusOne:-Christoffel3[mu, nu, alpha] = (1/2)*Physics:-ThreePlusOne:-gamma3_[mu, `~beta`]*(Physics:-d_[alpha](Physics:-ThreePlusOne:-gamma3_[beta, nu], [X])+Physics:-d_[nu](Physics:-ThreePlusOne:-gamma3_[beta, alpha], [X])-Physics:-d_[beta](Physics:-ThreePlusOne:-gamma3_[nu, alpha], [X]))

(2.1.7)

Ricci3[definition]

Physics:-ThreePlusOne:-Ricci3[mu, nu] = Physics:-d_[alpha](Physics:-ThreePlusOne:-Christoffel3[`~alpha`, mu, nu], [X])-Physics:-d_[nu](Physics:-ThreePlusOne:-Christoffel3[`~alpha`, mu, alpha], [X])+Physics:-ThreePlusOne:-Christoffel3[`~beta`, mu, nu]*Physics:-ThreePlusOne:-Christoffel3[`~alpha`, beta, alpha]-Physics:-ThreePlusOne:-Christoffel3[`~beta`, mu, alpha]*Physics:-ThreePlusOne:-Christoffel3[`~alpha`, nu, beta]

(2.1.8)

Riemann3[definition]

Physics:-ThreePlusOne:-Riemann3[mu, nu, alpha, beta] = Physics:-g_[mu, lambda]*(Physics:-d_[alpha](Physics:-ThreePlusOne:-Christoffel3[`~lambda`, nu, beta], [X])-Physics:-d_[beta](Physics:-ThreePlusOne:-Christoffel3[`~lambda`, nu, alpha], [X])+Physics:-ThreePlusOne:-Christoffel3[`~lambda`, upsilon, alpha]*Physics:-ThreePlusOne:-Christoffel3[`~upsilon`, nu, beta]-Physics:-ThreePlusOne:-Christoffel3[`~lambda`, upsilon, beta]*Physics:-ThreePlusOne:-Christoffel3[`~upsilon`, nu, alpha])

(2.1.9)

When working with the ADM formalism, the line element of an arbitrary spacetime metric can be expressed in terms of the differentials of the coordinates dx^mu, the Lapse , the Shift  and the spatial components of the 3D metric gamma3_ . From this line element one can derive the relation between the Lapse , the spatial part of the Shift , the spatial part of the gamma3_  metric and the g[0, j] components of the 4D spacetime metric.

For this purpose, define a tensor representing the differentials of the coordinates and an alias  dt = `#msup(mi("dx"),mn("0"))`

Define(dx[mu])

`Defined objects with tensor properties`



{Physics:-ThreePlusOne:-D3_[mu], Physics:-Dgamma[mu], Physics:-Psigma[mu], Physics:-ThreePlusOne:-Ricci3[mu, nu], Physics:-ThreePlusOne:-Shift[mu], Physics:-d_[mu], dx[mu], Physics:-g_[mu, nu], Physics:-ThreePlusOne:-gamma3_[mu, nu], Physics:-gamma_[i, j], Physics:-ThreePlusOne:-Christoffel3[mu, nu, alpha], Physics:-KroneckerDelta[mu, nu], Physics:-LeviCivita[alpha, beta, mu, nu], Physics:-ThreePlusOne:-Riemann3[mu, nu, alpha, beta], Physics:-ThreePlusOne:-TimeVector[mu], Physics:-ThreePlusOne:-ExtrinsicCurvature[mu, nu], Physics:-ThreePlusOne:-UnitNormalVector[mu], Physics:-SpaceTimeVector[mu](X)}

(2.1.10)

"alias(dt = dx[~0]):"

The expression for the line element in terms of the Lapse  and Shift   is (see [2], eq.(2.123))

ds^2 = (-Lapse^2+Shift[i]^2)*dt^2+2*Shift[i]*dt*dx[`~i`]+gamma_[i, j]*dx[`~i`]*dx[`~j`]

ds^2 = (-Physics:-ThreePlusOne:-Lapse^2+Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`])*dt^2+2*Physics:-ThreePlusOne:-Shift[i]*dt*dx[`~i`]+Physics:-gamma_[i, j]*dx[`~i`]*dx[`~j`]

(2.1.11)

Compare this expression with the 3+1 decomposition of the line element in an arbitrary system. To avoid the automatic evaluation of the metric components, work with the inert form of the metric %g_

ds^2 = %g_[mu, nu]*dx[`~mu`]*dx[`~nu`]

ds^2 = %g_[mu, nu]*dx[`~mu`]*dx[`~nu`]

(2.1.12)

Decompose(ds^2 = %g_[mu, nu]*dx[`~mu`]*dx[`~nu`])

ds^2 = %g_[0, 0]*dt^2+%g_[0, j]*dt*dx[`~j`]+%g_[i, 0]*dt*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`]

(2.1.13)

The second and third terms on the right-hand side are equal

op(2, rhs(ds^2 = dt^2*%g_[0, 0]+dt*%g_[0, j]*dx[`~j`]+dt*%g_[i, 0]*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`])) = op(3, rhs(ds^2 = dt^2*%g_[0, 0]+dt*%g_[0, j]*dx[`~j`]+dt*%g_[i, 0]*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`]))

%g_[0, j]*dt*dx[`~j`] = %g_[i, 0]*dt*dx[`~i`]

(2.1.14)

subs(%g_[0, j]*dt*dx[`~j`] = %g_[i, 0]*dt*dx[`~i`], ds^2 = dt^2*%g_[0, 0]+dt*%g_[0, j]*dx[`~j`]+dt*%g_[i, 0]*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`])

ds^2 = %g_[0, 0]*dt^2+2*%g_[i, 0]*dt*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`]

(2.1.15)

Taking the difference between this expression and the one in terms of the Lapse  and Shift  we get

simplify((ds^2 = dt^2*%g_[0, 0]+2*dt*%g_[i, 0]*dx[`~i`]+%g_[i, j]*dx[`~i`]*dx[`~j`])-(ds^2 = (-Physics:-ThreePlusOne:-Lapse^2+Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`])*dt^2+2*Physics:-ThreePlusOne:-Shift[i]*dt*dx[`~i`]+Physics:-gamma_[i, j]*dx[`~i`]*dx[`~j`]))

0 = (Physics:-ThreePlusOne:-Lapse^2-Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]+%g_[0, 0])*dt^2+2*dx[`~i`]*(%g_[i, 0]-Physics:-ThreePlusOne:-Shift[i])*dt-dx[`~i`]*dx[`~j`]*(Physics:-gamma_[i, j]-%g_[i, j])

(2.1.16)

Taking coefficients, we get equations for the Shift , the Lapse  and the spatial components of the metric gamma3_

eq[1] := coeff(coeff(rhs(0 = (Physics:-ThreePlusOne:-Lapse^2-Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]+%g_[0, 0])*dt^2+2*dx[`~i`]*(%g_[i, 0]-Physics:-ThreePlusOne:-Shift[i])*dt-dx[`~i`]*dx[`~j`]*(Physics:-gamma_[i, j]-%g_[i, j])), dt), dx[`~i`]) = 0

2*%g_[i, 0]-2*Physics:-ThreePlusOne:-Shift[i] = 0

(2.1.17)

eq[2] := coeff(rhs(0 = (Physics:-ThreePlusOne:-Lapse^2-Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]+%g_[0, 0])*dt^2+2*dx[`~i`]*(%g_[i, 0]-Physics:-ThreePlusOne:-Shift[i])*dt-dx[`~i`]*dx[`~j`]*(Physics:-gamma_[i, j]-%g_[i, j])), dt^2)

Physics:-ThreePlusOne:-Lapse^2-Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]+%g_[0, 0]

(2.1.18)

eq[3] := coeff(coeff(rhs(0 = (Physics:-ThreePlusOne:-Lapse^2-Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]+%g_[0, 0])*dt^2+2*dx[`~i`]*(%g_[i, 0]-Physics:-ThreePlusOne:-Shift[i])*dt-dx[`~i`]*dx[`~j`]*(Physics:-gamma_[i, j]-%g_[i, j])), dx[`~i`]), dx[`~j`]) = 0

-Physics:-gamma_[i, j]+%g_[i, j] = 0

(2.1.19)

Using these equations, these quantities can all be expressed in terms of the time and space components of the 4D metric g[0, 0] and g[i, j]

isolate(eq[1], Shift[i])

Physics:-ThreePlusOne:-Shift[i] = %g_[i, 0]

(2.1.20)

isolate(eq[2], Lapse^2)

Physics:-ThreePlusOne:-Lapse^2 = Physics:-ThreePlusOne:-Shift[i]*Physics:-ThreePlusOne:-Shift[`~i`]-%g_[0, 0]

(2.1.21)

isolate(eq[3], gamma_[i, j])

Physics:-gamma_[i, j] = %g_[i, j]

(2.1.22)

References




[1] Landau, L.D., and Lifshitz, E.M. The Classical Theory of Fields, Course of Theoretical Physics Volume 2, fourth revised English edition. Elsevier, 1975.



[2] Alcubierre, M., Introduction to 3+1 Numerical Relativity, International Series of Monographs on Physics 140, Oxford University Press, 2008.



[3] Baumgarte, T.W., Shapiro, S.L., Numerical Relativity, Solving Einstein's Equations on a Computer, Cambridge University Press, 2010.



[4] Gourgoulhon, E., 3+1 Formalism and Bases of Numerical Relativity, Lecture notes, 2007, https://arxiv.org/pdf/gr-qc/0703035v1.pdf.



[5] Arnowitt, R., Dese, S., Misner, C.W., The Dynamics of General Relativity, Chapter 7 in Gravitation: an introduction to current research (Wiley, 1962), https://arxiv.org/pdf/gr-qc/0405109v1.pdf





Examples: Decompose, gamma_



restartwith(Physics)NULL

Setup(mathematicalnotation = true)

[mathematicalnotation = true]

(2.2.1)

Define  now an arbitrary tensor A

Define(A)

`Defined objects with tensor properties`



{A, Physics:-Dgamma[mu], Physics:-Psigma[mu], Physics:-d_[mu], Physics:-g_[mu, nu], Physics:-KroneckerDelta[mu, nu], Physics:-LeviCivita[alpha, beta, mu, nu]}

(2.2.2)

So A^mu is a 4D tensor with only one free index, where the position of the time-like component is the position of the different sign in the signature, that you can query about via

Setup(signature)

[signature = `- - - +`]

(2.2.3)

To perform a decomposition into space and time, set - for instance - the lowercase latin letters from i to s to represent spaceindices and

Setup(spaceindices = lowercase_is)

[spaceindices = lowercaselatin_is]

(2.2.4)

Accordingly, the 3+1 decomposition of A^mu is

Decompose(A[`~mu`])

Array(%id = 18446744078724512334)

(2.2.5)

The 3+1 decomposition of the inert representation %g_[mu,nu] of the 4D spacetime metric; use the inert representation when you do not want the actual components of the metric appearing in the output

Decompose(%g_[mu, nu])

Matrix(%id = 18446744078724507998)

(2.2.6)

Note the position of the component %g_[0, 0], related to the trailing position of the time-like component in the signature "(- - - +)".

Compare the decomposition of the 4D inert with the decomposition of the 4D active spacetime metric

g[]

g[mu, nu] = (Matrix(4, 4, {(1, 1) = -1, (1, 2) = 0, (1, 3) = 0, (1, 4) = 0, (2, 1) = 0, (2, 2) = -1, (2, 3) = 0, (2, 4) = 0, (3, 1) = 0, (3, 2) = 0, (3, 3) = -1, (3, 4) = 0, (4, 1) = 0, (4, 2) = 0, (4, 3) = 0, (4, 4) = 1}))

(2.2.7)

Decompose(g_[mu, nu])

Matrix(%id = 18446744078724494270)

(2.2.8)

Note that in general the 3D space part of g[mu, nu] is not equal to the 3D metric gamma[i, j] whose definition includes another term (see [1] Landau & Lifshitz, eq.(84.7)).

gamma_[definition]

Physics:-gamma_[i, j] = -Physics:-g_[i, j]+Physics:-g_[0, i]*Physics:-g_[0, j]/Physics:-g_[0, 0]

(2.2.9)

The 3D space part of -g[`~mu`, `~nu`] is actually equal to the 3D metric "gamma[]^(i,j)"

"gamma_[~,definition];"

Physics:-gamma_[`~i`, `~j`] = -Physics:-g_[`~i`, `~j`]

(2.2.10)

To derive the formula  for the covariant components of the 3D metric, Decompose into 3+1 the identity

%g_[`~alpha`, `~mu`]*%g_[mu, beta] = KroneckerDelta[`~alpha`, beta]

%g_[`~alpha`, `~mu`]*%g_[mu, beta] = Physics:-KroneckerDelta[beta, `~alpha`]

(2.2.11)

To the side, for illustration purposes, these are the 3 + 1 decompositions, first excluding the repeated indices, then excluding the free indices

Eq := Decompose(%g_[`~alpha`, `~mu`]*%g_[mu, beta] = Physics[KroneckerDelta][beta, `~alpha`], repeatedindices = false)

Matrix(%id = 18446744078132963318)

(2.2.12)

Eq := Decompose(%g_[`~alpha`, `~mu`]*%g_[mu, beta] = Physics[KroneckerDelta][beta, `~alpha`], freeindices = false)

%g_[0, beta]*%g_[`~alpha`, `~0`]+%g_[i, beta]*%g_[`~alpha`, `~i`] = Physics:-KroneckerDelta[beta, `~alpha`]

(2.2.13)

Compare with a full decomposition

Eq := Decompose(%g_[`~alpha`, `~mu`]*%g_[mu, beta] = Physics[KroneckerDelta][beta, `~alpha`])

Matrix(%id = 18446744078724489454)

(2.2.14)

Eq is a symmetric matrix of equations involving non-contracted occurrences of `#msup(mi("g"),mrow(mn("0"),mo("&comma;"),mn("0")))`, `#msup(mi("g"),mrow(mi("j"),mo("&comma;"),mo("0")))` and `#msup(mi("g"),mrow(mi("j"),mo("&comma;"),mi("i")))`. Isolate, in Eq[1, 2], `#msup(mi("g"),mrow(mi("j"),mo("&comma;"),mo("0")))`, that you input as %g_[~j, ~0], and substitute into Eq[1, 1]

"isolate(Eq[1, 2], `%g_`[~j, ~0]);"

%g_[`~j`, `~0`] = -%g_[i, 0]*%g_[`~j`, `~i`]/%g_[0, 0]

(2.2.15)

subs(%g_[`~j`, `~0`] = -%g_[i, 0]*%g_[`~j`, `~i`]/%g_[0, 0], Eq[1, 1])

-%g_[0, k]*%g_[i, 0]*%g_[`~j`, `~i`]/%g_[0, 0]+%g_[i, k]*%g_[`~j`, `~i`] = Physics:-KroneckerDelta[k, `~j`]

(2.2.16)

Collect `#msup(mi("g"),mrow(mi("j"),mo("&comma;"),mi("i")))`, that you input as %g_[~j, ~i]

collect(-%g_[0, k]*%g_[i, 0]*%g_[`~j`, `~i`]/%g_[0, 0]+%g_[i, k]*%g_[`~j`, `~i`] = Physics[KroneckerDelta][k, `~j`], %g_[`~j`, `~i`])

(-%g_[0, k]*%g_[i, 0]/%g_[0, 0]+%g_[i, k])*%g_[`~j`, `~i`] = Physics:-KroneckerDelta[k, `~j`]

(2.2.17)

Since the right-hand side is the identity matrix and, from , `#msup(mi("g"),mrow(mi("i"),mo("&comma;"),mi("j")))` = -`#msup(mi("&gamma;",fontstyle = "normal"),mrow(mi("i"),mo("&comma;"),mi("j")))`, the expression between parenthesis, multiplied by -1, is the reciprocal of the contravariant 3D metric `#msup(mi("&gamma;",fontstyle = "normal"),mrow(mi("i"),mo("&comma;"),mi("j")))`, that is the covariant 3D metric gamma[i, j], in accordance to its definition for the signature `- - - +`

gamma_[definition]

Physics:-gamma_[i, j] = -Physics:-g_[i, j]+Physics:-g_[0, i]*Physics:-g_[0, j]/Physics:-g_[0, 0]

(2.2.18)

NULL

References




[1] Landau, L.D., and Lifshitz, E.M. The Classical Theory of Fields, Course of Theoretical Physics Volume 2, fourth revised English edition. Elsevier, 1975.

Example: Redefine



Tensors in Special and General Relativity



A number of relevant changes happened in the tensor routines of the Physics package, towards making the routines pack more functionality both for special and general relativity, as well as working more efficiently and naturally, based on Maple's Physics users' feedback collected during 2016.

New functionality


•

Implement conversions to most of the tensors of general relativity (relevant in connection with functional differentiation)

•

New setting in the Physics Setup  allows for specifying the cosmologicalconstant and a default tensorsimplifier




Download PhysicsMaple2017.mw

Edgardo S. Cheb-Terrab
Physics, Differential Equations and Mathematical Functions, Maplesoft

In this file you will be able to observe and analyze how the exercises and problems of Kinematics and Dynamics are solved using the commands and operators through a very well-structured syntax; Allowing me to save time and use it in interpretation. I hope you can share and spread to break the traditional and unnecessary myths. Only for Engineering and Science. Share if you like.

In Spanish.

Kinematics_using_syntax_in_Maple.mw

Lenin Araujo Castillo

Ambassador of Maple

   It’s that time of year again for the University of Waterloo’s Submarine Racing Team – international competitions for their WatSub are set to soon begin. With a new submarine design in place, they’re getting ready to suit up, dive in, and race against university teams from around the world.



   The WatSub team has come a long way from its roots in a 2014 engineering project. Growing to over 100 members, students have designed and redesigned their submarine in efforts to shave time off their race numbers while maintaining the required safety and performance standards. Their submarine – “Bolt,” as it’s named – was officially unveiled for the 2017 season on Thursday, June 1st.





   As the WatSub team says, "Everything is simple, until you go underwater."





    Designing a working submarine is no easy task, and that’s before you even think about all the details involved. Bolt needs to accommodate a pilot, be transported around the world, and cut through the water with speed, to name a few of the requirements if the WatSub team is to be a serious competitor.



    To help squeeze even more performance out of their design, the team has been using Maple to fine tune and optimize some of their most important structural components. At Maplesoft, we’ve been excited to maintain our sponsorship of the WatSub team as they continue to find new ways to push Bolt’s performance even further.





   The 2017 design unveiling on June 1st. After adding decals and final touches, Bolt will soon be ready to race.



   This year, the WatSub team has given their sub a whole new design, machining new body parts, optimizing the weight distribution of their gearbox, and installing a redesigned propeller system. Using Maple, they could go deep into design trade-offs early, and come away knowing the optimal gearbox design for their submarine.



   In just over a month, the WatSub team will take Bolt across the pond and compete in the European International Submarine Races (eISR). Many teams competing have been in existence for well over a decade, but the leaps and strides taken by the WatSub team have made them a serious competitor for this year.

  Best of luck to the WatSub team and their submarine, Bolt – we’re all rooting for you!

1 2 3 4 5 6 7 Last Page 1 of 36
